Specifications
Brand Name :
Zento
Model Number :
ZT-12C
Certification :
CE
Place of Origin :
CHIAN
MOQ :
2
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
1000
Delivery Time :
7-15 working days
Packaging Details :
Wooden case
Application :
Roads, Parks, etc.
Control Mode :
Remote Control
Diameter :
160mm
Height :
1000mm
Lifting Force :
20KN
Lifting Time :
5s
Material :
Stainless Steel
Product Name :
Hydraulic Rising Bollard
Protection Level :
IP67
Surface Treatment :
Polishing
Warranty :
1 Year
Weight :
100kg
Working Temperature :
-20℃~+60℃
Working Voltage :
220V
Description

Telescopic Security Hydraulic Rising Bollards

Automatic bollard:

This is new designed electric-hydraulic operated retractable bollard for roadblock management.
The system can be quickly and easily operated, suitable for both security and access control applications.
The system is designed to bring convenience and enhancements to higher level security. It is ideal choice for universities, pedestrian sidewalks, parking lots, government buildings, gyms, amusement parks, airports, shopping centers, hospitals, and occasions with high traffic flow.

350W Integrated Telescopic Security Hydraulic Rising Bollards 20KN

Product Feature

  • Pneumatic bollard systems, which are designed for several cycles, are perfect for limited parking lots, access control gates, commercial building entrances, and high-security applications such as military bases. With the stroke of a button, the bollard rises fast from the ground and descends just as quickly.
  • Engineered wiper seals minimise the amount of water and dust that enters the recess of the bollard. The bollard cylinders are available in a variety of diameters and wall thicknesses to suit any purpose. Most existing access control systems in a variety of situations may accommodate pneumatic auto-retractable bollards.
  • A bollard is a short post that is used to direct traffic and guard against vehicle incursions. Bollards can be designed and built to survive large vehicle accidents, but they can also be utilised as aesthetic barriers. Bollards can be used to protect against high-impact vehicle crashes. Steel pipe security bollards are constructed of structural grade steel and are intended to be embedded in and reinforced with concrete. Security bollards are appropriate for high-risk places such as building entrances, pedestrian walkways, and exposed utilities, where safety and security are critical.

350W Integrated Telescopic Security Hydraulic Rising Bollards 20KN

Product parameters

Control System Integrated Electro- Hydraulic
Passing pressure: ≤80- 120 tons container trucks
Voltage: AC220V 50Hz Integrated
System Dynamic power 350W Integrated
Rise time :

≤3-4S (adjustable)

(adjustable)

fall time :

≤3-4S (adjustable)

Material: 304 stainless steel
Rising height: 600mm
Diameter 168mm,219mm,273mm (can be customized)
External housing size

430*430*1130mm/500*500*900mm

Thickness of bollard 6mm,8mm,10mm.12mm,15mm,30mm (optional)
Working Temperature : -35℃~75℃(suitable)
Storage Environment : 10℃~65℃, Waterproof and moisture-proof

Solenoid valve voltage :

24V
Remote control distance Approx .50m-100m
Running noise ≤60 db
Waterproof: IP68, double sealed
Weight: 200 KG approx.
