High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
Specifications
Brand Name :
GFUVE
Model Number :
TEST-750
Certification :
ISO9001, CNAS, KEMA, CE, UL
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
200 Sets
Delivery Time :
3 - 7 Days
Packaging Details :
Standard Export Wooden Box
Max current :
150A
Max voltage :
AC250V or DC300V
Auxiliary AC voltage output Range :
0-250V ac
Resistor Resistance :
0.5Ω-2.5kΩ
Dimensions (W×D×H) (mm) :
340×270×260
Weight :
16.8kg
Timer :
0-9999.99ms
Name :
Single Phase Protection Relay Test Set
Description

TEST-750 150A Portable Single Phase Protection Relay Test Set With timer

TEST-750 single-phase protection relay test set high performance, portable to test in the field; it adopts aluminum alloy body with PC panel, robust shape; with the ARM chip control, LCD screen display single-phase protective relay test device of voltage and current output stopwatch;a full isolation, adjustable AC and DC voltage, AC direct current; an adjustable DC voltage and an adjustable AC voltage; output circuit with double overload protection, high output capacity, small size, light weight, high reliability. The equipment is suitable for a variety of relay field calibration and performance test.

GFUVE’s single phase relay test sets are essential items in the relay engineer’s toolbox. Lightweight, rugged with high compliance voltage and test current. Ideal for testing distribution networks, industrial relays, distance relays in rail power networks and many other applications.

Single-phase Relay Test Set up to 300V or 100A AC The TEST-750 equipment is a universal, portable, test system with an output to test single phase protective relays. The output channel is reversible and can be either Voltage or Current.

Features

  • High power current source for high burden relay test
  • Capable of testing differential relay with independent current sources
  • Capable of testing directional relay with adjustable phase angle
  • In-built Ammeter and Voltmteter
  • 120s output time at 150A
  • Rotating mouse control and quick control buttons
  • Blue blacklight LCD display
  • Many ready test modules for automatic test applications

Parameters

Electrical parameters
Rated input power
AC 220V±10% 1000VA·50/60Hz or
110V±10% 1000VA·50/60Hz
Turn on/turn off auxiliary contacts
Max current 1A
Max voltage AC250V or DC120V
AC output
Range 0-10A 0-40A 0-100A 0-100A
No-load Voltage(Min) 90V 25V 10V 10V
Full-load Voltage (Min) 80V 22V 8V 　
Full-load Current (Max) 10A 40A 100A 150A
AC/DC voltage output
Range 0-250V(AC) 0-300V(DC)
No-load Voltage(Min) 250V 320V
Full-load Voltage (Min) 240V 250V
Full-load Current (Max) 3A 3A
Auxiliary DC voltage output
Range 5-120V 110-220V
Max Voltage 120V 220V
Max Current 0.5A 0.5A
Auxiliary AC voltage output
Range 0-120V
Max voltage 120V
Max current 0.5A
Stopwatch
Range 0.0000-999999S
Resolution 0.1mS
Accuracy ±5 words
Max input voltage
(With contact and potential input)		 DC 250V
Ammeter
Range Inside 0.000-150.0A
Outside 0.000-6.000A(AC or DC)
Accuracy 0.50%
Voltmeter
Range 0.0-600.0V(AC or DC)
Accuracy 0.50%
Measuring mode AC True RMS
DC Average value
Resistor
Resistance 0.5Ω-2.5kΩ
Mechanical characteristics
Dimensions (W×D×H) (mm) 340×270×260
Weight 16.8kg
Mechanical parameters
Temperature -10°C to 40°C
Relative humidity <80%

The Product Picture:

High Power 150A Single Phase Relay Test Set With Timer Aluminum Alloy Body
