Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
Specifications
Brand Name :
Zhaoli
Model Number :
YJ62/300
Certification :
UL, CUL, CE, VDE, CCC, ROHS, REACH
Place of Origin :
China
MOQ :
2000pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
300,000pcs per day
Delivery Time :
20-40 days
Packaging Details :
cartons + wooden pallet
Name :
compressor nebulizer motor
Rated voltage :
220V 50HZ
Stack size :
62.5x62.5mm
Lamination :
25.5mm
Phase :
Single phase
Number of poles :
two
Insulation class :
CL.B
Bearing :
ball bearing or sleeve bearings optional
pump nozzle :
direction is flexible
Rated load :
Atomizing chamber
Time rating :
S1 (continuous)
Packing :
Customized packing
Printing :
Customized printing
Application :
Compressor nebulizer/Vacuum use/Inhaler
Description

Shaded Pole Motor Air Compressor Nebulizer Motor YJ62-25 220V 50HZ CL.B

Specification:

Rated voltage/frequency V/HZ 220V 50HZ
Rated current A 0.52A max
Rated input power W 55W max
Starting voltage V 198V max
Working air pressure PSI 8PSI min
Rated flow rate L/M 4.0L/M min
Max pressure PSI 30PSI min
Max flow rate L/M 14.0L/M

This kind of pump motor is composed by shaded pole motor with piston pump. A piston pump contains an accurately machined die-casted piston moving in a cylinder normally fitted with inlet and outlet valves.

Protection method: Thermal protectior 130℃

Motor Bearing: both ball bearings

Piston Bearing: ball bearing

Cooling fan size: φ75mm/ φ58mm


Drawing:

Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B

Application: Nebulizer

Shaded Pole 220V 50HZ Air Compressor Electric Motor 55W YJ62-25 CL.B
