Zhaoli YJ62 300 Nebulizer Compressor Motor 50HZ Pure Copper Wire
Zhaoli YJ62 300 Nebulizer Compressor Motor 50HZ Pure Copper Wire
Zhaoli YJ62 300 Nebulizer Compressor Motor 50HZ Pure Copper Wire
Zhaoli YJ62 300 Nebulizer Compressor Motor 50HZ Pure Copper Wire
Zhaoli YJ62 300 Nebulizer Compressor Motor 50HZ Pure Copper Wire
Zhaoli YJ62 300 Nebulizer Compressor Motor 50HZ Pure Copper Wire
Specifications
Brand Name :
Zhaoli
Model Number :
YJ62/300
Certification :
UL, CUL, CE, VDE, CCC, ROHS, REACH
Place of Origin :
China
MOQ :
2000pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
300,000pcs per day
Delivery Time :
20-40 days
Packaging Details :
cartons + wooden pallet
Name :
compressor nebulizer motor
Rated voltage :
230V 50HZ
Stack size :
62.5x60.5mm
Lamination :
25mm
Phase :
Single phase
Number of poles :
two
Insulation class :
CL.B
Bearing :
ball bearing or sleeve bearings optional
pump nozzle :
direction is flexible
Rated load :
Atomizing chamber
Time rating :
S1 (continuous)
Packing :
Customized packing
Printing :
Customized printing
Application :
Compressor nebulizer/Vacuum use/Inhaler
Description

Zhaoli Motor Nebulizer Compressor Motor YJ62/300 230V 50HZ Pure Copper Wire

Specification:

Rated voltage/frequency V/HZ 230V 50HZ
Rated current A 0.50A max
Rated input power W 60W max
Starting voltage V 200V max
Working air pressure PSI 9.5PSI min
Rated flow rate L/M 5.5L/M min
Max pressure PSI 34PSI min


Construction:

Insulation Class CL.B
Rotation Direction CCW (view from pump side)
Protection Thermal protector 140℃
Piston bearing Ball bearing
Nozzle direction Flexible, it can be four directions
Cooling fan size φ75mm


Drawing:

Zhaoli YJ62 300 Nebulizer Compressor Motor 50HZ Pure Copper Wire

Zhaoli YJ62 300 Nebulizer Compressor Motor 50HZ Pure Copper Wire

Application: Compressor nebulizer
