BLDC Three Phase Fan Motors 24V 33W FG Signal Ceiling Fan Brushless Motor
BLDC Three Phase Fan Motors 24V 33W FG Signal Ceiling Fan Brushless Motor
BLDC Three Phase Fan Motors 24V 33W FG Signal Ceiling Fan Brushless Motor
BLDC Three Phase Fan Motors 24V 33W FG Signal Ceiling Fan Brushless Motor
Specifications
Brand Name :
Zhaoli
Model Number :
E9T72H4BA6
Certification :
CE, ROHS, REACH
Place of Origin :
China
MOQ :
1000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1,000pcs per day
Delivery Time :
25-45 days
Packaging Details :
cartons + pallets
Name :
BLDC Ceiling fan motor
Rated voltage :
24VDC
Stack size :
φ92mm
Number of poles :
Eight poles
Number of phases :
three phase
Bearing :
Ball bearings
Construction :
Outer rotor
Control type :
PWM
Output signal :
FG
Rectifying method :
electronices
Packing :
Customized packing
Printing :
Customized printing
Anicilary :
Emitter and signal Receiver
Application :
Ceiling fan
Description

Brushless DC Motor BLDC Ceiling Fan Motor One Set Supply With Remote Control

  • Operating condition
Rated voltage 24VDC
Operating voltage 19.2~28.8VDC
Operating condition -10℃~40℃, RH 15%~90%
Storage condition -20℃~60℃, RH 5%~95%
  • Motor characteristics
Rated voltage 24VDC
Rated speed(on load) 260+/-5 RPM
Rated current(on load) 1.37A max
Rated power(on load) 33W max
Working duty S1
Insulation resistance 10MΩmin. (500VDC)
Dielectric strength 600VAC/1S leakage current <=5mA
Speed control PWM
Detecting method of motor speed FG signal
  • Emitter
Color Black or white
Type RF
Speed steps 5 steps
  • Motor controller (signal receiver)
Color black
Power Motor 33W max; Light 40W max
Character Vector sine wave control
Function
  • Through RF(433MHZ) to receive the transmitter signal and control accordingly.
  • Motor on and off; Motor on load speed; Motor Running time; Motor rotation direction
  • Light switch

Drawing:

BLDC Three Phase Fan Motors 24V 33W FG Signal Ceiling Fan Brushless Motor

Application: Ceiling fan

BLDC Three Phase Fan Motors 24V 33W FG Signal Ceiling Fan Brushless Motor
