Air Curtain Tangential Cross Flow Fans 240mm Blower Impedance Protected
Air Curtain Tangential Cross Flow Fans 240mm Blower Impedance Protected
Air Curtain Tangential Cross Flow Fans 240mm Blower Impedance Protected
Air Curtain Tangential Cross Flow Fans 240mm Blower Impedance Protected
Air Curtain Tangential Cross Flow Fans 240mm Blower Impedance Protected
Air Curtain Tangential Cross Flow Fans 240mm Blower Impedance Protected
Specifications
Brand Name :
Zhaoli
Model Number :
60-240
Certification :
UL, CUL, CE, VDE, CCC, ROHS, REACH
Place of Origin :
China
MOQ :
1000pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
300,000pcs per day
Delivery Time :
20-40 days
Packaging Details :
cartons + wooden pallet
Name :
tangential fan
Rated voltage :
220-240V 50/60HZ
Motor model :
YJ61-20
Insulation class :
CL.H
Motor protection :
Impedance protected
Blower size :
60x240mm
Blade material :
aluminium alloy
Frame :
Galvanized sheet steel
Bearing :
ball bearing or sleeve bearing optional
Mounting :
4 directions flexible
Color :
mainly original silver or black
Printing :
Customized printing
Packing :
Customized packing
Application :
Air curtain/Air conditioning/Freezers/Fireplaces
Description

60-240mm Cross Flow Fan Tangential Fan With Ac Shaded Pole Motor CL. H/B/E

Specification:

Motor Type AC shaded pole motor YJ61-20
Blower size 60X240mm
Rated voltage/frequency 230V 50HZ
Starting voltage <= 176V
Rated current <= 0.2A
Rated power 27+/20% W
Rated speed 2000+/- 10% RPM
Rising Temp. IEC60335-1
Lock Temp. IEC60335-1
High-voltage test 1800VAC/2mA/1S
Cold insulation resistance >= 100MΩ
End play 1.0mm max

Features:
1. The aluminium made alloy cross flow fan is temperature resistant and has qualities of light in weight, low noise, minimum vibration, high strength and long life.
2. The angle and length of cross flow fan leaves are easily adjustable to adapt to any customers' requirements.
3. The motor bearing is protected by a layer of grease which would allow 15000 hours of usage.

Drawing:

Air Curtain Tangential Cross Flow Fans 240mm Blower Impedance Protected

Application: This kind of cross flow fan is widely used in different industries, like hotels, construction works, home use appliances and so on. For example, Air curtain, Air conditioning, Freezers, Electric Fireplaces, Oven, Heater fan.

Air Curtain Tangential Cross Flow Fans 240mm Blower Impedance Protected
