ZT Customizable Automated Soldering Equipment With 200/400/600W Solder Power
ZT Customizable Automated Soldering Equipment With 200/400/600W Solder Power
ZT Customizable Automated Soldering Equipment With 200/400/600W Solder Power
ZT Customizable Automated Soldering Equipment With 200/400/600W Solder Power
Specifications
Certification :
CE, ISO, RoHS
Brand Name :
ZT
Model Number :
ZT-HXJ441-R
Place of Origin :
China
MOQ :
1 SET
Price :
USD 3100-3500/SET
Payment Terms :
T/T
Supply Ability :
100SET/Month
Delivery Time :
15-30 Day
Packaging Details :
Wooden box
Product Name :
Automatic Soldering Machine
Core Components :
PLC, Motor
Voltage :
AC 110~230V
Transport Package :
Wooden Box
Specification :
80*78*85cm
Soldering Iron Cooling Time :
Less than 20 seconds
Xyz Range :
X400*Y:400 *Z100mm
Solder Wire Diameter :
0.5, 0.6, 0.8, 1.0, 1.2mm
Aixs :
4
Editing Mode :
Teaching Pendant
Description

ZT Customizable Automatic Soldering Machine with 200/400/600W Solder Power

Product Advantage:

1. Improve product quality

The automatic soldering machine has high welding accuracy and precise temperature control, which can ensure the quality and stability of the solder joint, avoid welding defects caused by improper operation and fatigue during manual welding, and improve the reliability and service life of the product.

2. Reduce labor costs

The equipment can realize automatic welding, reducing the dependence on labor and reducing labor costs. At the same time, the efficient production capacity of the equipment can shorten the production cycle, improve production efficiency, and further reduce the production cost.

3. Enhance the competitiveness of enterprises

The use of automatic soldering machine for production, can improve the quality of products and production efficiency, enhance the market competitiveness of enterprises. At the same time, the high degree of automation of the equipment can enhance the image and brand value of the enterprise, and bring more opportunities for the development of the enterprise.

Product Parameter:

Name:
Automatic Soldering Robot
Place of Origin:
ShenZhen, China
Applicable Industries:
Manufacturing Plant, SMT , DIP
Key Selling Points:
Automatic
Video outgoing-inspection:
Provided
Weight (KG):
65Kg
Marketing Type:
New Product 2024
Voltage:
220/110V 50~60Hz
Warranty period:
1 Yea
Dimensions:
850*750*850mm
Warranty of core components:
3 Years
Solder Wire:
0.6~1.5mm solder wire
Core Components:
PLC
Temperature Accuracy
±3°
Power:
680W
Solder Feeding Speed
1~50mm/s
Current:
5A
Repeate Accuracy
±0.02mm

Specification:

Model
ZT-HXJ041R
ZT-HXJ441-R
ZT-HXJ4411-02
ZT-HXJ4411-02R
Fixture Customization
Solder Power
200W
200/400w 600W
200/400W
200/400/600W
Need
Heating Temperature Range
0-550ºC
Machine Axis Number
4axis
4axis
4axis
5axis
Max moving speed
X Axis
400mm
400mm
400mm
400mm/2X
600mm/s
Y Axis
300mm
300mm/2Y
300mm/2Y
300mm/2Y
600mm/s
Z Axis
100mm
100mm
100mm
100mm
400mm/s
R Axis
360°
360°
0
360°
±0.05° Error
Temperature Errors
±2°
Tin Wire Diameter
φ0.6mm-1.5mm
Teaching File Capacity
256MB, up to 999 files, single file up to 1000 points
Air Pressure
4-5kg/cm²
Weight(Kg)
58Kg
68Kg
75Kg
85Kg
Customized
Size(mm)
600*750*850
800*750*850
850*750*850
1000*750*850
To order
Detail Photos:

ZT Customizable Automated Soldering Equipment With 200/400/600W Solder PowerZT Customizable Automated Soldering Equipment With 200/400/600W Solder PowerZT Customizable Automated Soldering Equipment With 200/400/600W Solder PowerZT Customizable Automated Soldering Equipment With 200/400/600W Solder PowerZT Customizable Automated Soldering Equipment With 200/400/600W Solder Power

Our advantage:
ZT Customizable Automated Soldering Equipment With 200/400/600W Solder Power
1.We are factory manufacturers.

2.Reduce overall cost.

3.Improve automation level.

4.Improve informatization level.

5.Improve product yield.
6.Provide Customers With the Most Advanced
System Solutions for Automation Equipment.

Our Services:
Pre-Sale
 In Sale

After Sale
1.Product Introduction,

2.Technical Communication,
3.Remote consulting service.
1. Show the product,

2. Explain in detail how to use the product.

3. Answer the questions raised by customers.
1.Support video service.
2.The whole equipment is guaranteed for 1 year;
3.The guide rail/motor/control parts is guaranteed for 3 years.

FAQ:

1. who are we?
We are based in Guangdong, China, start from 2015, There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us?
Soldering machine,Precision spot welding machine,Glue dispenser,Screw machine
4. why should you buy from us not from other suppliers?
With ultra professional service and skill to provide high performance but competitive price goods, the customer's success is our own success.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,FCA,CPT; Accepted Payment Currency:USD,EUR,HKD,CNY; Accepted Payment Type: T/T,PayPal,Cash;
6.What is your Warranty for the product? How do you carry out it?
We provide 1 Year Warranty for unit machine and 3 years warranty for main board.More details pls contact me.
7. May I buy samples from you?
Yes! You are welcome to place sample order to test our superior quality and service.
8.Are you just trading company or factory?
We are professional manufacturer for automation machine since 2015.
