Industrial Digital Pressure Gauge , Digital Water Pressure Gauge Stable Performance
Industrial Digital Pressure Gauge , Digital Water Pressure Gauge Stable Performance
Specifications
Brand Name :
ZHYQ
Model Number :
ZH-S300
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3000 PCS / Week
Delivery Time :
7-10 days
Packaging Details :
Carton
Pressure range :
-1~0~600bar
Over load :
150%FS
Backlight color :
Blue , some is white
Dial size :
¢80mm
Accuracy grade :
0.2%
Reliability :
±0.2%FS/year
Working temperature :
-10～ 70℃
Supply voltage :
Battery
Description

Stable Performance Industrial Digital Water Pressure Gauge Meter

ZH-S300 is a new type digital pressure gauge,it can measure and display pressure at the same time . It is a long lifespan , high precision , good anti-vibration and easy to use . With 3 pressure units (MPa,kgf,psi) shift , reset function and LED local display, ZH-S300 is widely used in pressure measuring industry, heat pump pressure equipment, automation mechanical industry, etc .

This model adopts stainless steel material as housing material and connector material, with axel mounting and radial mounting available, it can meet different requirements from clients. It adopts import core as sensing element, so it’s of high reliability and cost performance.

Application

Mechanical and electronics industry
Industrial instruments ; Pressure laboratory
Construction machinery automation control field
Pressure vessel; Heat pump
Air compressor, Automation industry

Features
Four LCD local display, convenient for pressure reading
Pressure unit optional (MPa, psi, kgf); one key for auto-zero,
LCD backlight, auto shut-down functions
Low power consumption, battery power supply, which lasts 24 months
With high precision pressure transmitter inside, accuracy can be 0.1%FS

Specification

Pressure range -1~0~600bar
Over load pressure 150%
Power ≤0.5W
Rated current 20mA
Diameter 100mm
Accuracy grade ±0.5%F.S.
Reliability ±0.5%FS/year
Pressure unit MPa; kgf; psi
Supply voltage 12VDC ;24VDC ;220VAC ;380VAC available
Working temperature -20-80℃
Compensation temperature -10-60℃
Electric protection

Short-circuit protection; anti-reverse protection;

anti-electromagnetic interference
Sampling frequency 5 times per second
Tested medium Gas and liquid which is compatible with 316L material
Pressure connector M20*1.5; G1/2; G1/4 optional
Electric connector Cable lead
Mounting Radial or axle mounting available
Housing material Engineering plastics
Connector material 304 stainless steel

Ordering guide

Model

Range

(MPa)

 Output Screw Thread Power supply Accuracy Other requirement
ZH-S300 * N/O * * * ---
Example: ZH-S300-60MPa-G1/2-24VDC-0.5%
