TIF050AB-11S Two Component 5.0W/M-K Silicone Thermal Gel For Aerospace Electronic Equipment
TIF050AB-11S Two Component 5.0W/M-K Silicone Thermal Gel For Aerospace Electronic Equipment
TIF050AB-11S Two Component 5.0W/M-K Silicone Thermal Gel For Aerospace Electronic Equipment
TIF050AB-11S Two Component 5.0W/M-K Silicone Thermal Gel For Aerospace Electronic Equipment
Specifications
Brand Name :
Ziitek
Model Number :
TIF050AB-11S
Certification :
RoHS
Place of Origin :
Vietnam
MOQ :
1000 pcs
Price :
0.1-10 USD/PCS
Payment Terms :
T/T
Supply Ability :
100000pcs/month
Delivery Time :
3-5 work days
Packaging Details :
25*13*12cm carton
Products name :
TIF050AB-11S Two Component 5.0W/M-K Silicone Thermal Gel For Aerospace Electronic Equipment
Application :
Aerospace Electronic Equipment
Hardness :
45 Shore 00
Specific Gravity :
3.2g/cm³
Continuous Use Temperature :
-45~200℃
Color :
White / Gray
Thermal conductivity :
5.0W/mK
Keywords :
Silicon Thermal gel
Description

TIFTM050AB-11S Two Component 5.0W/M-K Silicone Thermal Gel For Aerospace Electronic Equipment

TIFTM050AB-11S is a highly thermal conductive, liquid gap filling material. It is provide with two-component and different temperature curing system. The product was supplied as highly thermal conductive, soft and elastomer for coupling on electrical devices modul. Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components. It is liquid approach offer variety of thickness, replacing individual die-cut and specific pad thickness. Different from grease, the cured product is dry and can be touch. It can intented for use in thermal applications.

Feature

< Good thermal conductive: 5.0WW/mK
< Two-part formulation for easy storage
< Exceilent low and high temperature mechanical and chemical stability
< Ultra-conforming low-stress interface application
< Ambient or accelerated cure schedules
< Optimized shear thinning characteristics for ease of dispensing
Applications

< Notebook
< Computer and peripherals

< Telecommunications

< Automotive electronics
< Thermally conductive vibrationd ampening
< Heat sink and any heatgenerating semicondutor

Typical Properties of TIFTM050AB-11S Series
Typical Uncured Material
Property Numerical Test Method
Color/Part A White Visual
Color/Part B Gray Visual
Viscosity as Mixed (cps) 1500 Pa.s GB/T 10247
Density 3.2g/cm3 ASTM D792
Mix Ratio 1:1 ******
Shelf Life@25℃ 6 months ******
Cure Schedule
Pot Life @25℃ 30 min Ziitek Test Method
Cure @25℃ 60 min Ziitek Test Method
Cure @100℃ 30 min Ziitek Test Method
Cure Properties
Color Gray Visual
Hardness 45 shore00 ASTM D2240
Continuous Use Temp -45~200℃ ******
Voltage Strength 275 V/mil ASTM D149
Dielectric Constant 4.5MHz ASTM D150
Volume Resistivity ≥1.0*1012 Ohm-cm ASTM D257
Flame Rating 94V0 E331100
Thermal Conductivity 5.0W/Mk ISO22007-2
Specific heat capacity 2.3 MJ/m³K ASTM D5470

Product packing details:
50cc/pc, 48pcs/box; 400cc/pc, 9pcs/box
We offer the custom packaged in Syringes for automated despensing applications. Please contact us for confirming.

TIF050AB-11S Two Component 5.0W/M-K Silicone Thermal Gel For Aerospace Electronic Equipment

Company Profile

Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.

FAQ

Q: Are you trading company or manufacturer ?

A: We are manufacturer in Vietnam.

Q: Do you accept custom orders ?

A:Yes , welcome to custom orders. Our custom elements including dimension , shape , color and coated on side or two sides adhesive or coated fiberglass. If you want to place a custom order , pls kindly offer a drawing or leave your custom order information.

Q:How can we get detailed price list?

A:Please offer us detailed information of the product such as Size(length,width,thickness),color,specific packaging requirements and purchasing quantity.
