Ceramic Wear Resistant 1780℃ 1800℃ Alumina Ceramic Products Plate
Ceramic Wear Resistant 1780℃ 1800℃ Alumina Ceramic Products Plate
Ceramic Wear Resistant 1780℃ 1800℃ Alumina Ceramic Products Plate
Ceramic Wear Resistant 1780℃ 1800℃ Alumina Ceramic Products Plate
Specifications
Brand Name :
China
Model Number :
008
Place of Origin :
Suzhou,China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 Piece/Pieces per Month
Delivery Time :
25 days
Packaging Details :
Box, Carton, Wooden, Bag etc. Customized package
Product name :
Advance Technical Ceramic Wear Resistant Alumina Ceramic Plate
Material :
Alumina Ceramic
Application :
Industrial Ceramic
Length :
3mm ~ 2000mm
Water Absorption :
0%
Electrical Insulation :
excellent
Density :
3.9g/cm3
Description

Advance Technical Ceramic Wear Resistant Alumina Ceramic Plate

Description:

Alumina ceramic is with superior strength, hardness, insulation, thermal conductivity, high temperature, oxidation resistance, corrosion resistance, abrasion resistance, high temperature strength and other characteristics. It has been widely used in engineering, mechanical seals, electronics, intrumentation, sensing, transport, communications,and other occasions or areas. The content of 99.7%, 99.5%, 99%, 96% alumina products contain the crucible, sockets, valves, electrodes, spools, wear board, alumina balls, rings, electronic porcelain, textile porcelain pieces and other shaped pieces.

Technical Parameters:

Test item/Unit Numerical Value Test item/Unit Numerical
Product Material Alumina Zirconia Product Material Alumina Zirconia
Component Content % ≥99% ≥95% ≥90% Volume Resistance MM >1012 >1012 >1012
Sintering Temp ℃ 1780-1800 1650-1680 1550-2600 Bending Strength Mpa 400 320 1100
Specific Gravity g/cm3 ≥3.8 ≥3.6 >6 Thermal Expansion Coefficient'10' 6.8-8.0 6.2-8.5 6.9-10
Breakdown Voltage
Strength kv/mm		 15 15 15 Roughness um ≤0.8 ≤0.8 ≤0.8
Bibulous Rate% <0.01 <0.01 <0.01 Mirror Polished Ra ≤0.05 ≤0.1 ≤0.05
Anti Pressure Mpa 3700Mpa 2400Mpa 5000Mpa Thermal Conductivity W/m.k 25 20 25
Hardness Hra ≥88 ≥82 ≥88 Temperature Resistance ℃ 1700 1600 1800


Advantages:

1.High strength and hardness.

2. Good wear resistance.

3. Insulation, corrosion resistance.

4. High lubrication and low resistance.

Application:

1.Ceramics, mines and other grinding equipment lining.

2·Material thansfer equipment.

3·inside and outside surface of powder separating equipment on iron and steel works.

4·Thermal and power plants.

More pictures:

Ceramic Wear Resistant 1780℃ 1800℃ Alumina Ceramic Products Plate

Ceramic Wear Resistant 1780℃ 1800℃ Alumina Ceramic Products Plate

Ceramic Wear Resistant 1780℃ 1800℃ Alumina Ceramic Products Plate
