Industrial Small Belt Conveyor Equipment / TD 75 Belt Conveyor
Industrial Small Belt Conveyor Equipment / TD 75 Belt Conveyor
Specifications
Brand Name :
ZK
Model Number :
Width(mm):400-1200
Certification :
CE ISO Certification
Place of Origin :
China
MOQ :
1 set
Price :
USD 8000-20000 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 Set / Sets per Month
Delivery Time :
30 days
Packaging Details :
Export standard container or as customers' requirements
Product Name :
Mobile Belt Conveyor , Small Mining Belt Conveyor ,Industrial Belt Conveyors
Condition :
New
After-sales Service Provided :
Engineers available to service machinery overseas
Warranty :
12 Months
Capacity :
30-480t/h
Material :
feldspar, quartz, clay, silica and other hard brittle materials
Motor type :
AC Motor
Spare parts :
Supply all using life
Voltage :
220V/380V/440
Description

Belt Conveyor Price / Small Mining Belt Conveyor / Industrial Belt Conveyors

Belt Conveyor Introduction:

Belt Conveyor is an ideal high-efficiency continuous conveyor and widely used in coal, transportation, water, electricity, mineral processing, chemical, food, metallurgy and other industries, which is able to improve the production efficiency.
According to different technique requirements, the machine can convey material singly or be formed conveying system with other conveying equipment to meet different requirements of working line.


Industrial Small Belt Conveyor Equipment / TD 75 Belt Conveyor


Advantages of Belt Conveyor:
1, The length can be adjusted according to users’ needs. It also can be used as a series by connecting each other to make up for the disadvantages of production environment. At the same time, it can reduce the use of labor force.
2, More automotive and easily controlled centralized. Besides, belt conveyor can adjust the transfer speed and the quantity of flow.
3, Because of its simple structure and light rack, it is easy for disassembling and assembling to make the dairy maintenance convenient.
4, Low investment cost. Rubber conveyor belt has strong universality and can be used in many industries.
5, conveyor belt can be extended and shortened according to the working needs and can adjust the driving equipment to meet the production needs.

Industrial Small Belt Conveyor Equipment / TD 75 Belt Conveyor


Small Mining Belt Conveyor Technical Parameters:

Model Rubber Belt

Conveying

Length(m)

 Diameter of Driving Drum
(mm)		 Max Feeding Size(mm) Capacity
(m³/h)

Power

(kW)
Width(mm) Speed
(m/s)		 Inclined
(°)
TD75-500 500 0.8～2.5 10～20° 2～240 400,500,630 100 69～217 1.5～30
TD75-650 650 0.8～2.5 10～20° 2～240 400,500,630 150 127～397 1.5～45
TD75-800 800 0.8～3.15 10～20° 2～240 400,500,630 200 198～781 2.2～75
TD75-1000 1000 0.8～3.15 10～20° 2～240 500,630,800 300 324～1622

7～100
