Powder Stainless Steel Screw Conveyor Reliable Operation Low Power Consumption
Powder Stainless Steel Screw Conveyor Reliable Operation Low Power Consumption
Powder Stainless Steel Screw Conveyor Reliable Operation Low Power Consumption
Powder Stainless Steel Screw Conveyor Reliable Operation Low Power Consumption
Specifications
Brand Name :
ZK
Model Number :
LS200-LS500
Certification :
CE ISO Certification
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 Set / Sets per Month
Delivery Time :
30 days
Packaging Details :
Export standard container or as customers' requirements
Product Name :
Stainless Steel Screw Conveyor Slag Steel Screw Conveyor
Condition :
New
After-sales Service Provided :
Engineers available to service machinery overseas
Warranty :
12 Months
Capacity :
7-90（m³/h）
Material :
feldspar, quartz, clay, silica and other hard brittle materials
Motor type :
AC Motor
Spare parts :
Supply all using life
Voltage :
220V/380V/440
Description

Screw, Stainless Steel Screw Conveyor for Powder of China Manufacture

LS Type Screw Conveyor Introduction:

Screw conveyor, used in electric power, chemical industry, metallurgy, coal, machinery, light industry:

LS type screw conveyor is international standard product, equivalent accord with the ISO1050-75 standard, design and manufacture accord with professional ZBJ1005.1-2-88 standard. Its advanced technical indicators, the structure is novel,it is our country in the ninety s to replace the replacement of the GX type screw conveyor.

Powder Stainless Steel Screw Conveyor Reliable Operation Low Power Consumption

Screw Conveyor in the Scope of Application:

screw machine is widely used in various industrial sectors, such as building materials, electric power, chemical industry, metallurgy, coal, machinery, light industry, food and food industry. The conveyor used to transport dry ash.

Screw Conveyor Require for Conveying Material:

powder, granulated and small lump materials, such as cement, coal, grain, chemical fertilizer, ash, sand, etc., the material temperature shall not exceed 200 ℃, screw machine should not transport perishable materials, big viscosity, easy to agglomerate. Because these materials in the transmission will be binding on the screw, and then rotate and do not move forward, or materials at suspension bearing product and make the screw machine can't work normally.

Powder Stainless Steel Screw Conveyor Reliable Operation Low Power Consumption

ZK CORP is a comprehensive enterprise focusing on equipment research and development, equipment manufacturing, and service. The company has rich design and manufacturing experience and many successful performances on the ash handling, slag handling, dust removing, desulfurization and denitration for CFB boiler and pulverizing coal boiler.

Technical Parameters:

Model Screwdia(mm)

Pitch

(mm)

Max Rev.Speed

(r/min)

 Capacity(m³/h) Conveying Distance(m)
LS200 200 200 50～90 7～12 2～15
LS250 250 200 45～90 10～20 2～20
LS300 300 300 40～80 15～30 2～20
LS400 400 300 35～70 25～55 2～25
LS500 500 400 35～65 45～90 2～25
Wearing Parts List:
No. Name Quantity
1 Flight 1
2 Bearing 2
3 Nylon Pin 8
