High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator
Specifications
Brand Name :
ZK
Model Number :
Magnetic separator
Certification :
ISO,CE
Place of Origin :
Henan, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10 per month
Delivery Time :
30days
Packaging Details :
Meet the shippment requirments
Model :
CTB6012-CTB1230
Capaicty :
20-160 (t/h)
Shell Length(mm) :
1200-3000
Shell Dia(mm) :
600-1200
Application :
Ore dressing, Recycling, Ceramic, Chemical industry
Dimension(L*W*H) :
Customer Request
Installation :
under our engineer's guide
Shipping Port :
Shanghai,Qingdao,Tianjin
Description

High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator

Magnetic separator introduction:

Magnetic separator is suitable for material with particle size below 3mm, it can use wet seperation process for magnetite, pyrrhotite, calcination ore, ilmenite and other materials, but also can remove iron from coal, non-metallic minerals, building materials etc. Its magnetic system adopt high quality ferrite material or material compound with rare-earth magnet material, the magnetic strength of drum surface is 100-600mT.

High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator


Working Principle:

When the raw materials flow into the tank body of the wet drum magnetic separator, firstly, the flowing direction of the raw materials is the same as the rotary direction of the magnetic drum, the iron magnetite materials are attracted to the surface of drum. This is the first separation. In the second step, the flushing water below flush the raw materials back for the second separation. This time the flowing direction of the raw materials is opposite to the rotary direction of the magnetic drum.

High Efficiency Magnetic Separator Machine , Iron Ore Magnetic Separator

OUR ADVANTAGES
1. The Magnetic separator can be down-flow, semi-countercurrent, countercurrent type according to customer’s need. There are different magnetic strength for each type.
2. Easy operation and maintenance, simple structure, stable and reliable performance
3. The advantage of magnetic separator is simple structure,large process capacity, easy operation and maintenance and so on.

Parameter:


Model

DrumDia(mm)

DrumLength(mm)

 Rotate Speed r/min Feed Size
mm		 Capacity
t/h		 Power
Kw
CTB6012 600 1200 <35 2-0 10-20 1.5
CTB6018 600 1800 <35 2-0 15-30 2.2
CTB7518 750 1800 <35 2-0 20-45 2.2
CTB9018 900 1800 <35 3-0 40-60 3
CTB9021 900 2100 <35 3-0 45-60 3
CTB9024 900 2400 <28 3-0 45-70 4
CTB1018 1050 1800 <20 3-0 50-75 5.5
CTB1021 1050 2100 <20 3-0 50-100 5.5
CTB1024 1050 2400 <20 3-0 60-120 5.5
CTB1218 1200 1800 <18 3-0 80-140 5.5
CTB1224 1200 2400 <18 3-0 85-180 7.5
CTB1230 1200 3000 <18 3-0 100-180 7.5
