Specifications
Brand Name :
ZONCN
Model Number :
T9400-5R5G
Certification :
CE
Place of Origin :
China
MOQ :
1 PC
Payment Terms :
T/T,Paypal
Supply Ability :
100,000 pcs/month
Delivery Time :
7-30 days
Packaging Details :
inside: box; outside: carton
Type :
variable frequency drivers
Brand :
ZONCN
Voltage :
380v
Power :
7HP/5.5kw
Communication :
RS485/Profinet
Braking unit :
Built-in
PID control :
Built-in
24V terminal :
Have
Warranty :
18 months
Delivery time :
within 15 days normally
Description

VFD 7.5kw Variable Frequency Drivers 380v Variadores De Frecuencia 10hp

Application Fields of ZONCN T9000 Series Inverters

The ZONCN T9000 series is a high-performance variable frequency drive (VFD) designed for demanding industrial and commercial applications. Its advanced vector control technology, robust construction, and intelligent features make it suitable for a wide range of industries. Here are its key application areas:

  1. Industrial Automation – The T9000 excels in automated production lines, CNC machines, and robotic systems, providing precise speed and torque control for improved efficiency.

  2. HVAC Systems – It optimizes the performance of fans, pumps, and compressors in heating, ventilation, and air conditioning (HVAC) systems, reducing energy consumption by up to 50%.

  3. Water & Wastewater Treatment – Used in water supply pumps, sewage treatment, and filtration systems, the T9000 ensures smooth operation and energy savings in municipal and industrial water management.

  4. Material Handling – Ideal for conveyors, cranes, and hoists, it enables soft starts/stops, preventing mechanical shocks and extending equipment lifespan.

  5. Oil & Gas Industry – The T9000’s high torque and overload capacity make it suitable for drilling rigs, pipeline pumps, and compressors in harsh environments.

  6. Textile & Printing Machinery – Ensures precise speed synchronization in spinning, weaving, and dyeing machines, improving product quality.

  7. Food & Beverage Processing – Complies with hygiene standards while controlling mixers, conveyors, and packaging equipment efficiently.

  8. Renewable Energy Integration – Supports solar/wind-powered pumping systems, enhancing energy efficiency in green applications.

  9. Mining & Heavy Machinery – With strong heat dissipation and dust resistance, it reliably powers crushers, lifts, and ventilation systems.

ZONCN T9000 Inverter Model

High Performance VFD VSD Inverter Manufacturing 3.7kw 5.5kw 380v AC Drives

ZONCN T9000 Inverter Model Input Voltage (V) Rated output power(kW) Rated input current(A) Rated output current(A) Motor Power (KW)
T9200-0R4G 1PH AC 220V±15% 0.4 5.4 2.5 0.4
T9200-0R75G 0.75 7.2 5 0.75
T9200-1R5G 1.5 10 7 1.5
T9200-2R2G 2.2 16 11 2.2
T9200-3R7G 3.7 17 16.5 3.7
T9200-5R5G 5.5 26 25 5.5
T9200-7R5G 7.5 35 32 7.5
T9400-0R4G 3PH AC 380V±15% 0.4 3.4 1.2 0.4
T9400-0R75G 0.75 3.8 2.5 0.75
T9400-1R5G 1.5 5 3.7 1.5
T9400-2R2G 2.2 5.8 5 2.2
T9400-3R7G/5R5P 3.7/5.5 10/15 9/13 3.7/5.5
T9400-5R5G/7R5P 5.5/7.5 15/20 13/17 5.5/7.5
T9400-7R5G/11P 7.5/11 20/26 17/25 7.5/11
T9400-11G/15P 11/15 26/35 25/32 11/15
T9400-15G/18.5P 15/18.5 35/38 32/37 15/18.5
T9400-18.5G/22P 18.5/22 38/46 37/45 18.5/22
T9400-22G/30P 22/30 46/62 45/60 22/30
T9400-30G/37P 30/37 62/76 60/75 30/37
T9400-37G/45P 37/45 76/90 75/90 37/45
T9400-45G/55P 45/55 92/113 90/110 45/55
T9400-55G 55 113 110 55
T9400-75G/90P 75/90 157/180 150/176 75/90
T9400-90G/110P 90/110 180/214 176/210 90/110
T9400-110G/132P 110/132 214/256 210/253 110/132
★Please contact us directly for inverter powers above 110kw

Inverter Specification

Item Description
Basic function Control Mode VF control
Sensorless flux vector control(SVC)
Close-loop vector control(FVC)(Above 3.7kW)
Maximum frequency 0~600Hz
Carrier frequency 0.5kHZ——8kHz
The carrier frequency is automatically adjusted based on the load features
Input frequency resolution Digital setting:0.01Hz
Analog setting: Maximum frequency x 0.025%
Start torque G Type:0.5Hz/150%(SVC)
P Type:0.5Hz/100%
Speed range 1:100 (SVC)
Speed stability accuracy ±0.5%(SVC)
Overload capacity G Type:60s for 150% of the rated current, 3s for 180% of the rated current. P Type:60s for 120% of the rated current, 3s for 150% of the rated current.
Torque boost Auto-boost ;
Customized boost: 0.1%~30.0%
V/F Curve Straight-line V/F curve
Multi-point V/F curve
N-power V/F curve (1.2-power, 1.4-power, 1.6-power, 1.8-power, square)
V/F separation 2 types: complete separation; half separation
Ramp Mode Straight-line ramp.
Four groups of acceleration/deceleration time with the range of 0.00`6500.0s
DC braking DC braking frequency:0.00Hz~Maximum frequency
Braking time:0.0s~36.0s
Braking action current value:0.0%~100.0%
JOG control JOG frequency range:0.00Hz~50.00Hz
JOG acceleration/deceleration time: 0.0s~6500.0s.
Simple PLC,Multiple preset speeds It implements up to 16 speeds via the simple PLC function or combination of terminal states
Onboard PID It realizes process-controlled closed loop control system easily
Auto voltage regulation(AVR) It can keep constant output voltage automatically when the mains voltage
Overvoltage/overcurrent stall control The current and voltage are limited automatically during the running process so as to avoid frequent tripping due to over voltage/over current
Rapid current limit It helps to avoid frequent over current faults of the AC drive.
Torque limit and control It can limit the torque automatically and prevent frequent over current tripping during the running process. Torque control can be
implemented in the FVC mode.
　 Support for multiple PG card Support for differential input PG card, resolver PG card ,rotating transformer PG card
