HVAC DC2.5V Ball Valve Motor Torque 1.8NM Flow Control
HVAC DC2.5V Ball Valve Motor Torque 1.8NM Flow Control
HVAC DC2.5V Ball Valve Motor Torque 1.8NM Flow Control
HVAC DC2.5V Ball Valve Motor Torque 1.8NM Flow Control
Specifications
Brand Name :
Runpaq
Model Number :
K18-DN15
Certification :
NONE
Place of Origin :
China
MOQ :
1000 pieces
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
200000 sets/month
Delivery Time :
15-21 days
Packaging Details :
carton
Voltage rating :
3.6VDC
Work voltage :
2.5V - 5V DC
Empty run current :
<25 mA (23 C) by motor #320
Current at full loading :
about 550 mA
Motor :
DC5V #320 motor
Torque :
1.8 NM (1400:1) / 2NM (2000:1) / 3NM (4200:1)
Open / close time :
< 8 S (1400:1) / 10 S (2000:1) / 3NM (4200:1)
Reduction ratio :
1400:1 & 2000 : 1 (For DN15 , DN20), 4200:1 for DN25
Product name :
geared synchoronous motor actuator, mini motorised valve actuator
Model :
K18
Description

ball valve actuator motor, DC2.5V, Torque 1.8NM flow control

Product description

The DC2.5-5V motor actuator are designed for water flow control or heat control in water utility, HVAC, such as mini motorized ball valve , smart water meter with ball valve, zone valve, heat control valve.The ball valve diameter range: DN15, DN20, DN25, DN32, DN40, up to DN80.The torque range from 1.8NM to 4.5 NM.


Technical data-Model K18
1. Voltage: DC3.6 V (Range: DC2.5 - 5 V, the higher the voltage, the larger torque, the shorter life span)
2. Current at idle: <25 mA @ 3.6V, 23ºC
3. Current with max loading: <550 mA (motor #320)
4. Torque: >1.8 NM (1400:1), >2NM (2000:1), >2.5NM (3400:1), >3NM (4200:1)
5. Open/close time: <8S (1400:1), <10S (2000:1), <15S (3400:1), <18S (4200:1)
6. Velocity reduction ratio: (1400:1), (2000:1), (3400:1), (4200:1)
7. Protection: 0

Wiring definition

No Color of wire Definition
1 blue on position signal, valve open
2 white on position signal, public
3 yellow on position signal, valve close
4 black positive (+)
5 red negative (-)

Production overview
HVAC DC2.5V Ball Valve Motor Torque 1.8NM Flow ControlHVAC DC2.5V Ball Valve Motor Torque 1.8NM Flow ControlHVAC DC2.5V Ball Valve Motor Torque 1.8NM Flow Control
