Ball Valve DC3.6V Zone Valve Motor Actuator step motor 2NM Torque
Ball Valve DC3.6V Zone Valve Motor Actuator step motor 2NM Torque
Ball Valve DC3.6V Zone Valve Motor Actuator step motor 2NM Torque
Ball Valve DC3.6V Zone Valve Motor Actuator step motor 2NM Torque
Specifications
Brand Name :
Runpaq
Model Number :
K11-DN15
Certification :
NONE
Place of Origin :
China
MOQ :
1000 pieces
Price :
USD2.28/piece (>2000 pieces) USD2.5 / piece (1000 - 2000 pieces)
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
200000 sets/month
Delivery Time :
15-21 days
Packaging Details :
carton
Rated voltage :
DC3.6V
Voltage range :
DC2.5V - DC5V
Work current at 3.6V :
<25 mA (23 C)
Current at max loading :
about 550 mA
Motor :
Geared synchornized step motor #320
Torque :
2 NM
Open / close time :
< 10 S
Reduction ratio :
2000 : 1 (For DN15, DN20 motorized ball valve)
Product name :
ball valve actuator motor
Model :
K11
Description

V8043 zone valve motor actuator, step motor actuator for zone control valve 2NM

Product description

Our DC electric actuator motors are designed for mini motorized ball valve, which can be attached to irrigation water meter, IC card prepay water meter, heat meter, motorized ball valve to control the electric ball valve open or close. The synchronous geared motor is an electric motor actuator in which, at steady state, the rotation of the shaft is synchronized with the frequency of the supply current; the rotation period is exactly equal to an integral number of electric cyles.


Technical data-Model K11
1. Voltage: DC3.6 V (Range: DC2.5 - 5 V, the higher the voltage, the larger torque, the shorter life span)
2. Current at idle: <25 mA @ 3.6V, 23ºC
3. Current with max loading: <550 mA (motor #320)
4. Torque: >2 NM
5. Open/close time: <10S
6. Velocity reduction ratio: 2000:1
7. Protection: IP0

Wiring definition

No Color of wire Definition
1 blue on position signal, valve open
2 white on position signal, public
3 yellow on position signal, valve close
4 black positive (+)
5 red negative (-)

Production overview
