DN15 Thermostatic Water Mixing Valve , Brass PN10 Radiator Control Valve
DN15 Thermostatic Water Mixing Valve , Brass PN10 Radiator Control Valve
DN15 Thermostatic Water Mixing Valve , Brass PN10 Radiator Control Valve
DN15 Thermostatic Water Mixing Valve , Brass PN10 Radiator Control Valve
Specifications
Brand Name :
Runpaq
Model Number :
KTF06-DN15
Certification :
NONE
Place of Origin :
China
MOQ :
1000 pieces
Price :
USD14/piece (500-1000 pieces) , USD10.5 (>1000 pieces)
Payment Terms :
D/P, T/T, L/C, D/A, Western Union
Supply Ability :
200000 sets/month
Delivery Time :
15-21 days
Packaging Details :
carbon + pallet
Valve body material :
brass, stainless steel SS304, 316
Work current :
<80 mA
Work voltage :
DC3-6V / DC12V / AC85-230VAC
Pressure rating :
PN10, 10 bar, 1.0 Mpa, 150 psi
Open / close time :
<13 S
Torque :
2.5 NM
Power :
2 w
Protection :
IP65
Description

Underfloor heating temperature control valves, water control valve for boiler, dN15, PN10 brass

General description

The underfloor heating temperature control valves, are also called zone heating valves, which is ideally suited to the temperature control of individual underfloor heated rooms and for systems using floor heating in conjuction with radiators.

Our advantages

  • More than 50 types, diameter ranges from DN15 to DN40, it features small torque, low electricity consumption,leak-proof, high pressure rating.
  • Customized production available, thanks to our strong mechanical machining and milling capability
  • Sturday valve body with reasonable structure design, and best material to be used

DN15 Thermostatic Water Mixing Valve , Brass PN10 Radiator Control Valve DN15 Thermostatic Water Mixing Valve , Brass PN10 Radiator Control Valve

No Name Material Advantage
1. O-ring

Import

fluoro rubber (green)

 Resistance to high temperature, oil, corrosion, chemicals, Work temp.: —30℃+280℃.Quadruple seals, minimize the risk of leakage.
2. Drainage Drain just in case leakage happens
4 0-ring EPDM (red) Between nut and valve body, extra external leak proof, reduce the possibility of internal leak
8. Ball Brass or SS304 Finely polished, rack nickel plating (not barrel plating), smooth surface, improved torque performance
9. Water proof G Avoid water into housing, seal between valve body and valve housing
No Name Material Advantages
5. Wall thickness 2.0mm, PN20
6. Teflon washer Import teflon

1. Import teflon tube, numerical processing to perfectly match with ball surface

2. Minimal deformation, polish surface, wearable
7 0-ring EPDM

1. Good elasticity, as buffer after Teflon washer to improve seal effect

2. Reasonable structure design, ensures perfect holding margin

Product dimensions

Valve body material Connection port Diameter D L H W
(mm) (Kg)
Brass Both female thread full diameter DN8 8 46 31 0.357
DN15 15 57 38 0.433
DN20 20 71 45 0.513
DN25 23.5 72 49 0.603
Both female threaded reduced diameter DN10 8 46 31 0.356
DN20 15 66 38 0.448
DN25 20 72 47 0.608
DN32 25 86 60 0.82
3-way vertical DN15 12 63 49 0.434
DN20 15 66 53 0.492
Female-male thread full port DN15 15 63 38 0.432
Female-male thread reduce port DN20 15 66 38 0.462
Both male thread DN15 15 68 38 0.424
Stainless steel Both female thread full diameter DN8 8 46 31 0.364
DN15 15 55 38 0.44
DN20 20 71 45 0.508
DN25 25 72 49 0.617
Both female threaded reduce diameter DN15 8 46 30.5 0.368
DN20 15 63 39 0.513
DN25 20 75 47 0.608

Applications range

  • HVAC, heating supply systems
  • Air conditioning systems
  • Baseboard/radiant heating
  • Convectors
  • Fan coil units
  • Floor heating
  • Unit ventilators
  • VAV reheat
