Specifications
Place of Origin :
Hunan, China
Brand Name :
Achieve
Supply Ability :
5 Unit/Units per Month
Price :
$50,000.00 - $55,000.00/Units
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction works , Energy & Mining
Condition :
New
Voltage :
440V
Power :
23
Dimension(L*W*H) :
12*12*3M
Weight :
20Ton
Warranty :
1 Year
UNIQUE SELLING POINT :
High operating efficiency
After-sales Service Provided :
Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Online support
Description

HGY29S-3R Factory Concrete Spreader Concrete Distributor Concrete Placing Boom

Full hydraulic control of all boom movements provides smooth, precise control. The load sensing, proportional, pressure compensated hydraulic system provides accurate, predictable boom placement even during multi-function operation.

Extensive application of modular design technology and quick connecting components allows rapid assembly and hoisting of placing booms.

The German manufactured Siemens programmable login controller (PLC) is equipped with local, wired or 100m ultra long distance remote control.

This reliable system can be operated within four user selectable frequency bands.

HGY29S-3R NEW Concrete Pump Spreader / 440V 20Ton Placing Boom Concrete Pump

Technical Specifications

Model of Placing Boom

HGY29S-3R

HGY29P-3R

HGY29SC-3R

HGY29PC-3R

Performance

Max. Radius (m)

29

Free Standing Height,Slewing Range

22.7m,400°

Working temperature(℃)

0~60℃

Counter weight(kg)

/

2930

Total weight(kg)

19100

22030

Supply power to equipment

380V/50Hz

Electric motor

Motor Model

Y2-160L-4

Power(kw)

15

Hydraulic system

System pressure(MPa)

32

Flow(L/min)

18

Oil tank capacity(L)

280

Control mode

(Cable+Radio) remote control

Clearing mode for concrete pipe

Water clear / Dry clear

Section of tubular column (m×m)

0.75×0.75

Arm(Booms)

Boom model

fully hydraulic foldable arms

Delivery pipeline diameter

DN125mm

Length of end hose

DN125mm×3000mm

The first section

Length(m)

10.9

Articulation

-2.5°~82.5°

The second section

Length(m)

9.6

Articulation

0°~180°

The third section

Length(m)

8.5

Articulation

0°~180°

Climbing

Climbing Mode

Cylinder Jack Lifting

Internal Climbing Step Distance(m)

0.52

Floor Frame

Hole Prepared in Floor

Shaft Frame

Size of Climbing Shaft : 2.0m-2.7m

Min. Space Between Internal Climbing Frame

Climbing(m)

3

Placing Concrete(m)

6

Rest(m)

6

HGY29S-3R NEW Concrete Pump Spreader / 440V 20Ton Placing Boom Concrete Pump
