LT-CR Series Crystal Oscillator With Broadband Frequency 0.1MHz To 200MHz
LT-CR Series Crystal Oscillator With Broadband Frequency 0.1MHz To 200MHz
Specifications
Brand Name :
ZR Hi-Tech
Model Number :
LT-CR-O-50M-2013
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T
Delivery Time :
4 weeks
Packaging Details :
carton packing
Product name :
LT-CR series crystal oscillator
Application :
Various electronic equipment and instruments in the field of national defense
Features :
Low Power Consumption
Material :
Aluminum
Temperature :
-40~125℃
Frequency range :
0.1MHz~200MHz
Operating Voltage :
3.3~5.5V
Color :
Silver
Description

0.1MHz~200MHz LT-CR Series Crystal Oscillator

Quick Detail:

· Aluminum housing

· Broadband Frquency

· -40℃~+125℃ operating temperature

· SMD package

· High precision

· Low phase noise

· CMOS Output Waveform

· CE, RoHS, REACH compliant

· 1 Year Warranty


Description:

The LT-CR-O-50M-2013 is the newest addition to ZR’s line of Crystal Oscillator (XO) with a CMOS output from 0.1 to 200 MHz. This XO requires a supply voltage of 3.3V to 5.5V. They are available in a hermetically sealed surface-mount package and measure 20.5x7.6x5.3mm. These XOs are widely used in various electronic equipment and instruments in the field of national defense.


Specifications:
Electrical / Optical Characteristics (Ta=25℃±3℃)

ItemsSpecificationConditions
Part NumberLT-CR-O-50M-2013
Frequency Range

0.1MHz~200MHz
Operating Voltage

3.3~5.5
Frequency Stability vs. Temperature±30ppm@-40~85℃
±100ppm@-55~125℃
Output WaveformCMOS
Output Load15pF
Duty Cycle(%)45~55
Rise/Fall Time(ns)

0.1MHz≤F0＜10MHz

＜200.1Vdd→0.9Vdd

10MHz≤F0＜40MHz

＜10

40MHz≤F0＜100MHz

＜6

100MHz≤F0＜200MHz

＜3
Current Consumption(mA)

0.1MHz≤F0＜40MHz

＜53.3V non-loaded

40MHz≤F0＜60MHz

＜15

60MHz≤F0＜100MHz

＜25

100MHz≤F0＜200MHz

＜40
Dimension20.5x7.6x5.3mm
Note: for custom specs, please contact us directly.





Outline Drawing (Unit: mm):

LT-CR Series Crystal Oscillator With Broadband Frequency 0.1MHz To 200MHz


LT-CR Series Crystal Oscillator With Broadband Frequency 0.1MHz To 200MHz

PINFunction
1Suspended
7GND
8Output
14Input
