LMV324DR2G
LMV324DR2G
Specifications
Brand Name :
ON SEMI
Model Number :
LMV324DR2G
Place of Origin :
MY
MOQ :
5000pcs
Supply Ability :
10000pcs in stock
Packaging Details :
T&R
Voltage Amplifier :
5v, 14 PIN
Description

Op Amp Quad Low Voltage Amplifier R-R O/P 5V 14-Pin SOIC N T/R

Product Technical Specifications

EU RoHS Compliant
ECCN (US) EAR99
Part Status Active
HTS 8542.33.00.01
Type Low Voltage Amplifier
Manufacturer Type Low Voltage Amplifier
Number of Channels per Chip 4
Rail to Rail Rail to Rail Output
Output Type CMOS
Maximum Input Offset Voltage (mV) 9@5V@-40C to 85C
Minimum Single Supply Voltage (V) 2.7
Typical Single Supply Voltage (V) 3
Maximum Single Supply Voltage (V) 5
Maximum Input Offset Current (uA) 0.001(Typ)@5V@-40C to 85C
Typical Input Bias Current (uA) 0.001@5V@-40C to 85C
Maximum Supply Current (mA) 0.83@5V
Power Supply Type Single
Typical Slew Rate (V/us) 1@5V
Typical Input Noise Voltage Density (nV/rtHz) 50@5V
Typical Voltage Gain (dB) 100
Minimum PSRR (dB) 50
Minimum CMRR (dB) 50
Minimum CMRR Range (dB) 50 to 60
Typical Gain Bandwidth Product (MHz) 1
Shut Down Support No
Minimum Operating Temperature (°C) -40
Maximum Operating Temperature (°C) 85
Supplier Temperature Grade Industrial
Packaging Tape and Reel
Pin Count 14
Standard Package Name SOP
Supplier Package SOIC N
Mounting Surface Mount
Package Height 1.5(Max)
Package Length 8.75(Max)
Package Width 4(Max)
PCB changed 14
Lead Shape Gull-wing
