ZXC European Type Jaw Crusher

Jaw Crusher is suitable for primary and secondary crusher for material with compression strength less than 320MPA.

Product features of stone jaw crusher

Jaw Crusher is ideally suitable for primary and secondary crusher for material with compression strength less than 320MPA. Jaw Crusher is of high crushing ratio, larger capacity, well-distributed product size, simple structure, reliable performance, convenient maintenance, lower operation and cost, etc. It is widely used in mining, metallurgy, construction, highway, railroad, and water conservancy, etc.

Jaw Crusher is of crushing ratio, capacity, product size, simple structure, reliable , convenient maintenance, lower operation cost, etc.

The electrical motor transmits power to the eccentric shaft through vbelt and belt pulley. Then the exciting force generated by the eccentric shaft will make the movable jaw move upwards and downwards. This movement would trigger the toggle plate to push the movable jaw forwards and backwards. When the movable jaw moves forth towards the fixed jaw, materials in the crushing cavity will be squashed or chopped. And then the movable jaw travels back, the chopped or squashed materials which meet the requirement will be discharged from the outlet. Since the motor keeps working. The crusher will crush and discharge periodically to achieve mass production

It is widely used in mining, metallurgy, construction, highway, railroad, and water conservancy, etc

1. Good crushing cavity design:

Adopt "V"-shaped crushing cavity and large inclination switching plate, so that the feeding size is large and the output is high.

2. Reliability

The good manufacturing process and materials used to achieve the reliability of the structure.

3. High strength

The movable jaw plate is optimized by finite element analysis technology, and the bearing seat is completely made of cast steel, which can ensure the matching of the frame, increase the radial strength of the bearing seat, and make the whole machine have high strength.

4. The adjustment of the discharge port is quicker and more convenient

ZXC series European jaw crusher adopts special adjustment device, which is simpler and more convenient than ordinary old wedge adjustment.

5. Choose a larger type of bearing with higher bearing capacity

ZXC series European jaw crusher is equipped with larger type of bearing, which has higher bearing capacity and labyrinth seal will prolong the service life of the bearing.

Work site

Specification
