Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-LD550FK
Certification :
CE/Rohs/FCC/ERP Energy Label
Place of Origin :
Guangdong, China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight case are option
Type :
LCD
Color :
customized
Supplier Type :
Original manufacturer, ODM, Agency, Retailer, Other, OEM
Usage :
Outdoor Adverting Display
Certificate :
CE/CCC/FCC/ROHS/ISO9001
OEM :
Support
Brightness :
max 1000nit, 1500nit
Lifespan (hours) :
60000h
Installation Type :
floorstanding
Display Ratio :
16:9
Keywords :
Outdoor Digital Display Board
Description

Freestanding 55 inch Readable Waterproof Monitor LCD Digital

Advertising Screen Outdoor Digital Display Board

1. Product Introduction

Wide Temperature Range: -20℃ to 70℃

ZXTLCD Outdoor Digital Signage is designed for outdoor environments and interactive commercial displays. With a 6-layer PCB circuit board design and optimized layout, the size is controlled at 120*75mm, saving valuable space. To adapt to complex usage environments, it is made using immersion gold technology with corrosion-resistant gold fingers on the core board, ensuring stable operation 24/7 even in temperatures ranging from -20℃ to 70℃.

The containment structure The material and feature of shell IP65 outdoor cabinet, 1.5mm zinc coated steel, waterproof and anti-dust design.
Glass feature with 6mm Tempered explosion-proof Glass above the screen panel
LCD Panel Screen Size 55 inch
Display area 1214mm(H) X 684mm(V)
Aspect Ratio 9:16
LCD Type TFT-LCD
Max Resolution 1920X 1080
Display color 16.7M
Brightness 1500 cd/㎡ ~ 2000cd/㎡
Contrast Ratio 4000:1
Viewing angle(up/down/left/right) 178°/178°/178°/178°
Response Time 6ms
Field Frequency 60Hz

Cost-Effective Processor

Equipped with a low-power quad-core processor and Android 7.1 operating system, it offers high performance at an excellent cost-to-performance ratio. The processor operates at a maximum frequency of 1.2GHz.

Buit-in Media Player Ads updated type USB copy by manual operation
RAM 2GB
Flash memory card 16GB
Plug-and-Play Plug-and-play /No windows OS, Auto loop play when power on
Media Format Video format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio format MP3, WMA
Photo format BMP, JPEG, PNG, GIF etx
Interface HDMI 1
USB 2
SD cassette TF(Micro SD )card, scalable 32G
ECU Switch power supply Industrial Power supply
Waterproof speaker High quality waterproof 10W speaker
Thunder Preventer The tree-level lightning protection
Leakage protective device Defend Electricity Leakage
Timer Set up on/off time on day/week/month

HD Display Output

Supports HDMI/LVDS display output, with a maximum resolution of 1080P for both HDMI and LVDS screens and decoding.

Peripheral and Network Communication

All peripheral interfaces are designed with surge protection and anti-static measures. It supports 1x 100Mbps Ethernet with auto-negotiation, built-in Wi-Fi, and optional Bluetooth connectivity.

Built-in Fan for Ventilation Intelligent Straight ventilation Cooling system Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed
Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically
Environment Working temperature below 40℃ ~ + 55℃
Working humidity 5% ~ 95%
Working Voltage AC 100 ~240v , 50Hz
Max Power Consumption 280W
The dimension of machine To be determined
Outer Package size and Gross weight

Extensive Customization Support

Offers deep customization options for both software and hardware, including CPU, motherboard, and memory specifications. It supports popular operating systems such as Windows 10 or 11, Android 11, and can run all software compatible with the corresponding system.

2. More Details

Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board

Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board

Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board

Freestanding 55 inch Readable Waterproof Monitor LCD Digital Advertising Screen Outdoor Digital Display Board

If you are interested in the product or have other questions, please feel free to contact us Via WhatsApp.
