21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table
21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table
21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table
21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table
21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table
21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-TB215CTR01
Certification :
CE/Rohs/FCC/ERP Energy Label
Place of Origin :
Guangdong province, China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight case are option
OS :
Windows 10 / 11 or Android 11.0 version
Size :
21.5 Inch
Max Resolution :
1920 X 1080 / 3840 X 2160
Contrast Ratio :
4000: 1
Application :
Indoor
Warranty :
3 Years
Processor :
Cortex-A55 Quad core, 1.8Ghz
CPU :
Intel 6th Gen I5-6200U
Touch Technology :
Capacitive touch
Keywords :
Costomizatble / Touch Screen Table / touch screen coffee table
Description

21.5 Inch Customizable Size OS Smart Interactive Multitouch System

Lcd Advertising Panel Touch Screen Table

1. Product Introduction

A dual-purpose solution - a table and tablet combined!

In the meeting room of daily life or work, the Interactive flat panel can be used as a coffee table. It has super waterproof performance and wear resistance, which can meet your daily use. In addition, it also saves you the money of a tablet, you can use the touch table as a tablet, a larger screen to watch videos or play games, very suitable for interacting with children, accurate and sensitive flat capacitive screen Simple, stylish, and beautiful, every touch is just right, and the screen is also very easy to clean without sticking foreign objects.

Enjoy a crisp 1080P Full HD display for stunning visuals.

The Interactive flat panel features a 1080P full HD waterproof screen, delivering exquisite and lifelike visuals for a truly immersive experience while watching videos or playing games. It offers the ultimate look and feel, providing the perfect opportunity to have fun with friends and family. The touch table is compatible with both Android and Windows systems, catering to the diverse needs of various groups of people.

2. Product parameter

LCD Panel

LCD Panel Screen Size 21.5 Inch
Display area 476mm(H) X 268mm(V)
Aspect Ratio 16:09
LCD Type TFT-LCD (WLED Backlight)
Max Resolution 1920 X 1080 / 3840 X 2160
Display color 16.7M
Brightness 450cd/m2
Contrast Ratio 1000:1
Viewing angle(up/down/left/right) 178°/178°/178°/178°
Response Time 6ms
The lifetime of screen panel > 60,000hours

Touch Screen Parameter

Touch screen parameter Touch style Projected Capacitive Touch screen
Touchpoints 10 points
The glass transmittance >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88%
Response speed < 15ms
Accuracy of touch More than 90% of the touch area ±2mm
Touch ways sensitive to pens, prostheses, fingers, brushes and any non-transparent object
Output format The coordinate output
Clicks time Unlimited
The smallest touch size 5mm
Long resistance Yes available
Touch Interfaces USB
Operating temperature & Humidity below10℃ ~ +50℃, ≤ 85%RH
Storage temperature & Humidity below20℃ ~ +60℃, ≤ 90%RH

OS Configuration

Internal Android Media Player PCB board
Configuration		 Processor Cortex-A55 Quad-core processor, 1.8Ghz
RAM 2GB
ROM 16GB
OS Android 11.0 version
Built-in wifi 150Mbps 802.11n wifi integrate
Built-in Mini PC(Optional) CPU Intel 6th Gen I5-6200U processor,
RAM 8GB
Storage volume 120GB SSD
OS Windows 10 / 11
Built-in wifi 150Mbps 802.11n wifi integrate
Media Format Video format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4, etc.
Audio format MP3, WMA
Photo format BMP, JPEG, PNG, GIF etx
Onboard interface Network port RJ45, 10M/100M Adaptive Ethernet
HDMI 1
USB 2 USB 2.0 PORTS
Power Audio system Built-in 10 W X 2 Speakers
Power supply AC 100V~240V, 50/60Hz
The Max power loss ≤ 230w
Standby power loss < 1W

Features

Features Operating temperature 0℃ ~ 50℃
Storage temperature below20℃ ~ +60℃
Enclosure Front panel 4 mm thick protective glass
Frame color white / Black / Silver option
Installation type Floor standing
Application Indoor
Touch Table Dimension of machine Customization

3. More Details

21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table

21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table

21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table

21.5 Inch Customizatble Size OS Smart Interactive Multitouch System Lcd Advertising Panel Touch Screen Table

If you are interested in the product or have other questions, please feel free to contact us Via WhatsApp.
