Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign
Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign
Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign
Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXT-OTP430E
Certification :
CE/Rohs/FCC/ERP Energy Label
Place of Origin :
China
MOQ :
1 Piece
Price :
Negotiate
Payment Terms :
T/T,Western Union, Alibaba trade assurance
Supply Ability :
1,000 pcs per month
Delivery Time :
25-35 workdays
Packaging Details :
wooden case, carton, flight case are option
Product name :
Outdoor Information Kiosk
Touch Screen :
Capacitive Touch
Sizes :
32'' 43'' 49'' 55'' 65''70'' 85''
Waterproof :
IP65
Application :
Outdoor
Material :
Metal Case + Toughened Glass Panel
Description

Capcitive Touch Standing Outdoor Waterproof Information Kiosk Road Advertising Sign Interactive Way Finder

Main features

1. IP65 design for outdoor application.

2. High brightness up to 2000cd/m2, readable under sunlight.

3. Build in Airconditioner cooling system, adapted to -40°C--+60°C environment temperature.

4. Fron tempered glass and anti-glare glass

5. Intelligent light system, brightness of screen auto adjusts according to environment light, saving energy.

6. Anti-dust, anti-vandal, anti-theft.

7. Customized design for you without additional cost.

8. Screen sizes available 19-82inch

9. Wall mount, roof hanging and free standing(fixed on ground) all available.

10. Security electric circuit design

11. Build in power timer

Items

Touch Screen Specifications

Touch type

Infrared sensor

Typical feature

Dustproof, vandal proof, anti-sunlight

Touch points

Multi 2points to 32points

Accuracy

±2mm

Light transmittance

Over 92%

Surface hardness

7H

Output resolution

4096X4096

Respond time

Less than 8ms

Life span

Over 60,000,000 single point touch

Items

Touch Foil Film Specifications

Touch type

Projected capacitive touch

Typical feature

Touch through tempered glass

Touch points

Multi 2points to 40points

Accuracy

≤1mm

Light transmittance

Over 95%

Scanning speed

16ms

Output solution

4096X4096

Safe distance

At least 3mm (between TFT LCD and touch foil)

Life span

7-9 years

Specification:

screen specs

Screen size:

55"

Display ratio:

16:9

Resolution(Pixel):

1920*1080

View angle :

89/89/89/89

Luminance:

1500 cd/m2,2000cd/m2 , 2500cd/m2 , 2500cd/m2 , 3000cd/m2

3500cd/m2 ,4000cd/m2 ,5000cd/m2

Contrast ratio:

5000:1

Response time :

8ms

Display area:

1209.6*680.4 mm

Touch screen optional

Capacitive touch screen / Infrared touch screen / Nano touch screen

Parameter

Operating temperature:

-40°C--+60°C

Protection Rating:

IP65

Storage Temperature:

0-50 degrees

Humidity :5%-100%

Temperature control system(optional)

Air conditioner

Voltage Rated:AC110V/60Hz OR other

Current Rated:AC 6.5A

Power Rated:AC 500W

Cooling Capacity:1500W(L35 L35)

Heating Capacity:500W(optional)

Ambient Temperature:-20℃~55℃

IP Grade:IP65

Radiator

Working Pressure:2bar-40bar

Specification: 2Kw-400Kw

Power supply

AC Input:

110-240V, 50/60Hz

Operating system(optional)

Standalone version

RAM:8G SD play

Android version

Quad core cortex A8, All winner A31 ,1.2GHz 1G DDR3, android 4.4.2 or above.

Windows pc

Quad-core pc / i3 / i5 / i7 intel core

Appearance

Color option:

Silver, white, black or optional

Enclosure material

Zinc coated steel+front tempered glass

Installation:

Wall mounting/roof hanging/floor standing

I/O interface:

1*USB,1* SD/MMC/MS card slot ,
HDMI/DVI/VGA optional

Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign

Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign

Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign

Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign
