49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight
49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight
49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight
49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXT-IK490B
Certification :
CE/Rohs/FCC/ERP Energy Label
Place of Origin :
China
MOQ :
1 Piece
Price :
Negotiate
Payment Terms :
T/T,Western Union, Alibaba trade assurance
Supply Ability :
2,000 pcs per month
Delivery Time :
10-12 working days
Packaging Details :
wooden case, carton, flight case are option
Sizes :
43''/49''
Type :
Floor Stand Kiosk
Touch Screen :
IR/Capacitive/Foil touch optional
WIFI / 3G/ RJ45 :
Support
Tempered Glass Protection :
yes
Brightness :
360cd/m2
Description

43/49 Inch Standing Touch Screen All In One Information Health Kiosks

Product Description

Main Features

1. Humanization sleek & smart design

2. Metal wiredrawing craft on the frame

3. Automobile metal black or silver painting

4. Movable touch monitor with build-in PC

5. Multi touch operation

6. Various application

7. Worldwide certificate approval, such as RoHS, CE, and FCC

49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight

TFT LED display

Items TFT LED Display Specifications
Size 43 inch
Brand Samsung / LG/ChiMei/AUO
Display area(mm) 941*530
Aspect ratio 16:9
Resolution 1920X1080
Color 16.7M
Dot pitch(mm) 0.297X0.297
View angle 178°/178°
Brightness 450nits
Contrast 5000:1
Respond time 6ms
Life span (hrs) Over 60,000

Touch Screen:

Items Touch Screen Specifications
Touch type Infrared sensor
Typical feature Dust-proof, explosion-proof, anti-sunlight
Touch points Multi 2points to 32points
Accuracy ±2mm
Light transmittance Over 92%
Surface hardness 7H
Output resolution 4096X4096
Respond time Less than 8ms
Life span Over 60,000,000 single point touch

Items Touch Foil Film Specifications
Touch type Projected capacitive touch
Typical feature Touch through tempered glass
Touch points Multi 2points to 40points
Accuracy ≤1mm
Sensor 56 sensor to multi 2points, 64X64 sensor to multi 4points to 40points
Light transmittance Over 95%
Scanning speed 16ms
Output solution 4096X4096
Safe distance At least 3mm (between TFT LCD and touch foil)
Life span 7-9 years

49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight

Ø PC configurations (it can be changed per the demand of clients)

Items PC Configurations
CPU Intel I3-3110
Mother board Intel HM65
Memory DDR3 4GB
Hard disk SATA 500GB
Graphic card Integrated HD graphic card
Audio card Integrated Realtek ALC889 8 channels
Network card 1000M Realtek RTL8111E
Speaker Sony origin 2X10w loud speaker
Interfaces USB
Operating System Windows 8 (English trial version)

Ø Kiosk

Items Kiosk Specifications
Material 2-3mm metal plate
Metal cut Metal is cut by Laser Machine without burr
Surface finish Automobile paint (carbon black or silver white)
Voltage input AC 110V – 240V
Power plug America standard, Europe standard
Work temperature 0°C to 40°C
Storage temperature -20°C to 60°C
Humidity 20%-80%

49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight

Applications

Ø Business organizations

l Supermarket, Shopping mall, Hotel, Restaurant, Pharmacy

Ø Non-profit organizations

l Airport, Railway / bus station, Exhibition, Museum, Hospital, School, Convention center, Lottery station, Government affairs center

Ø Financial organizations

l Bank, Insurance company, Foundation, Security company

Ø Entertainments

l Movie theater, Club, Bar, Salon, Gambling house

49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight

Packaging & Shipping

Packaging Details: Foam, Carton, Wooden Case.
Delivery Details: 4-5 weeks for sample order, 5-6 weeks for large order.

49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight

Our Services

1. Full testing before shipping.
2. 12 months free warranty.
3. Agency Approvals: Ce, RoHS, FCC.

49 Inch Health Interactive Touch Screen Kiosk Floor Stand Infrared Sensor Anti - Sunlight
