Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-E236BACTWFS
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight cases are optional
Screen Size :
23.6 inch
Aspect Ratio :
16:9
Brightness :
250 cd/m²
Install Type :
Embedded, open-frame, wall-mounted, floor-standing
Suitable Environment :
Outdoor; Indoor
Applications :
Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an
OS :
Android 11
RAM+ROM :
2+32GB; 4+32GB
Description

23.6-Inch Android Touch Screen for Smart Retail and Logistics Dashboards

The 23.6-inch Android touchscreen is designed to enhance the functionality of smart retail systems, making it a perfect solution for interactive kiosks, digital price tags, and customer-facing displays. Retailers can utilize this device to showcase dynamic product information, promotions, and advertisements with its bright 1920x1080 resolution and vivid color reproduction. This makes it an excellent tool for improving the customer experience in stores by offering interactive shopping features, product recommendations, and digital catalogs. With a responsive capacitive touchscreen interface, customers can easily browse through items, select options, and access additional details with just a touch, elevating the shopping experience. The integrated Android system also allows for easy software management and content updates, making it ideal for retail businesses looking to enhance their digital infrastructure.

LCD Panel Parameters Screen Size 23.6 Inch
Display Area 522 mm.(Height) X 294(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 16.7m , 72% NTSC
Brightness 250cd/
Contrast Ratio 1000 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 14ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 100Hertz
PCAP Touchscreen Panel Parameters Touch Pattern Projected Capacitive Touchscreen Monitor
Touch Points 10 Points
Cover Glass Morse Glass Size 7 Physically reinforced to prevent explosion
Glass 3 mm. Optical mount to reduce parallax
Glass Transmission >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85%
Response Speed < 6ms
Touch Accuracy More than 90% of the touch area ±2 mm
Touch Method Inch Stylus
Output Format Coordinate Output
Click Time Unlimited
Smallest Touch Size 5 mm
Long-lasting Durability Yes, Available
Touch Interface USB
Operating Temperature and Humidity Below 10 ~ +50, ≤ 85%RH
Storage Temperature and Humidity Less than 20 ~ +60, ≤ 90%RH
Audio parameters Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Configuration PCB Android Built-in
(Choose one of two)
CPU Quad-Core RK3288, 1.8GHz Quad-Core RK3568,2.0GHz
GPU Mali-T764 Mali-G52
RAM 2GB 4GB
ROM 32GB 32GB
Android System Android 10.0 Android 11.0
Ethernet 1 x RJ45, Ethernet 1,000 Mbps 1 x RJ45, Ethernet 1,000 Mbps
Wireless Internet 2.4Gigahertz 2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth 4.2 5
Interface USB2.0 x 2 USB2.0 x 2
HDMI IN x 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 45 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Package Size Device Dimensions 564.4 X 340.4 X 55.7mm.
Net Weight 8 Kilogram
Package Size 54 X 42 X 15Centimeter
Gross Package Weight per Unit 9 Kilogram

In logistics and warehouse management, this 23.6-inch touchscreen serves as an ideal dashboard for real-time tracking and monitoring. With its high-resolution display and wide viewing angles, it provides a clear and accessible view of key performance metrics, inventory levels, and shipment status updates. Warehouse operators can use the device to interact with supply chain management software, ensuring efficient inventory control and logistics operations. The Android-powered system allows for seamless integration with inventory and tracking applications, allowing workers to update stock, manage orders, and check shipment statuses with ease. The touchscreen's durability, paired with its robust build, makes it well-suited for the fast-paced and demanding environments found in warehouses and distribution centers.

23.6-Inch Android Touch Screen for Smart Retail and Logistics Dashboards

23.6-Inch Android Touch Screen for Smart Retail and Logistics Dashboards23.6-Inch Android Touch Screen for Smart Retail and Logistics Dashboards23.6-Inch Android Touch Screen for Smart Retail and Logistics Dashboards23.6-Inch Android Touch Screen for Smart Retail and Logistics Dashboards

This 23.6-inch touchscreen is also a powerful tool in the creation of real-time dashboards for operational monitoring in industries like manufacturing and transportation. Displaying metrics such as machine performance, production speeds, and transportation schedules, the device allows managers and operators to monitor systems with high clarity and precision. The ability to display multiple data streams simultaneously ensures that businesses can track various operations in one place, enabling quick decision-making and responsiveness. Its compact form factor and touch interface make it an efficient solution for streamlining workflows across multiple departments, from production lines to transportation hubs, making it an essential tool for industries focused on operational efficiency and data-driven decision-making.
