10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems
10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems
10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems
10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-E101BL
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight cases are optional
Screen Size :
10.1 inch
Aspect Ratio :
16:9
Brightness :
400 cd/m² max 1000 cd/m²
Install Type :
Embedded, open-frame, wall-mounted, floor-standing
Suitable Environment :
Outdoor; Indoor
Applications :
Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an
RAM+ROM :
4+128GB; 8+256GB
Description

10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems

LCD Panel Parameters Screen Size 10.1 Inch
Display Area 217 mm.(Height) X 135.6(Width)mm.
Aspect Ratio 16 : 9 16 : 10
LCD Type a-Si TFT-LCD Monitor a-Si TFT-LCD Monitor
Maximum Resolution 1280 X 800 1920 X 1200
Display Color 16.7M, 50% NTSC 16.2M , 50% NTSC
Brightness 400cd/m² 1000cd/m²
Contrast Ratio 900 : 1 1000 :1
Viewing Angle (Up/Down/Left/Right) 85°/85°/85°/85° (Type)(CR≥10) 80°/80°/80°/80° (Type)(CR≥10)
Response Time 30ms 30ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Internal computer configuration
(Choose one of two)		 CPU Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics Card Integrated Graphics Card Intel® HD 4600 Integrated Graphics Card Intel® HD 530
RAM 4GB 8GB
Storage Memory Capacity 128GB 256GB
OS Linux Linux
Wi-Fi Built-in Speed 150Mbps 802.11n wifi Integrated Speed 150Mbps 802.11n wifi Integrated
Media Format Video Format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio Format MP3, WMA
Photo Format BMP, JPEG, PNG, GIF etc.
Onboard Interface Network port RJ45 X 1, 10M/100M Adjustable Ethernet
HDMI 1
USB 4
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 15 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0℃ ~ 50℃
Storage Temperature Below 10℃ ~ +60℃
Stereo Speaker Length 1.5m
Package Size Device Dimensions 259.62 X 177.62 X 41.6 mm.
Net Weight 2 Kilogram
Package Size 31 X 23.3 X 11Centimeter
Gross Package Weight per Unit 4 Kilogram

10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems

10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems10.1-Inch Linux Industrial Display Terminal for Process Monitoring, Factory Equipment, Smart Logistics, and Medical Systems
