The 17-inch Android display is specifically designed for warehouse operations and smart factory applications, offering a powerful tool to streamline logistics, inventory management, and process control. With a high-resolution 1280x1024 screen and wide viewing angles, it ensures that operators can monitor real-time data clearly from various positions within large warehouses or factory floors. The device is equipped with Wi-Fi and Ethernet connectivity, allowing seamless integration with warehouse management systems (WMS), enabling real-time updates on inventory levels, shipments, and production progress. The Android operating system offers flexibility, allowing businesses to customize the user interface and applications to suit specific operational requirements, whether for tracking inventory, managing supply chains, or monitoring production lines.
LCD Panel Parameters | Screen Size | 17 Inch | ||
Display Area | 337.92 mm.(Height) X 270.34(Width)mm. | |||
Aspect Ratio | 16 : 9 | |||
LCD Type | a-Si TFT-LCD Monitor | |||
Maximum Resolution | 1280 X 1024 | |||
Display Color | 16.7M , 72% NTSC | |||
Brightness | 250cd/m² | |||
Contrast Ratio | 1200 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
Response Time | 20ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 60Hertz | |||
Audio parameters | Audio system | Stereo | ||
Speaker size | ≈ 99 x 45 x 20 mm | |||
Impedance | 8 Ohm | |||
Power | 2 x 5 Watt | |||
Loudness | > 80 Decibel | |||
Interface | 4-pin connector | |||
Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
GPU | Mali-T764 | Mali-G52 | ||
RAM | 2GB | 4GB | ||
ROM | 32GB | 32GB | ||
Android System | Android 10.0 | Android 13.0 | ||
Ethernet | 1 x RJ45, 1,000 Mbps | Ethernet 1,000 Mbps | ||
Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
Bluetooth | 4.2 | 5 | ||
Interface | USB2.0 x 2 | OTG USB2.0 x 1 | ||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 30 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 380 X 318 X 49mm. | ||
Net Weight | 5.5 Kilogram | |||
Package Size | 45 X 38.5 X 15Centimeter | |||
Gross Package Weight per Unit | 6 Kilogram |
In smart factory environments, the 17-inch monitor serves as an essential component for real-time data visualization and machine-to-machine (M2M) communication. With its quad-core CPU and Android OS, it allows easy integration with industrial IoT devices, making it a powerful tool for operators to monitor and control factory systems from a centralized hub. From predictive maintenance systems that alert operators to potential equipment failures, to production line control displays that show step-by-step instructions or output status, this monitor enhances overall operational efficiency. Furthermore, its sturdy build and wide temperature tolerance make it suitable for deployment in harsh factory environments, where it can withstand industrial vibrations and fluctuating temperatures.
In logistics and distribution centers, the 17-inch Android monitor is an invaluable tool for improving order fulfillment and shipping accuracy. It can be used as a pick-to-light or scan-to-verify station, helping operators quickly verify orders and inventory before shipping. With its multi-interface connectivity, including USB and Ethernet ports, it can interface with barcode scanners, RFID systems, and cloud-based applications to retrieve and display up-to-the-minute order data, making it easier to manage large-scale warehouse operations. Additionally, its Wi-Fi 6 support ensures faster communication with other networked devices and systems, while its compact and durable design makes it an ideal solution for tight spaces and high-traffic areas in warehouses. The display's low power consumption also contributes to energy efficiency, further enhancing its suitability for long-term operations.
