Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-E215WLB
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight cases are optional
Screen Size :
21.5 inch
Aspect Ratio :
16:9
Brightness :
400 cd/m²
Install Type :
Embedded, open-frame, wall-mounted, floor-standing
Suitable Environment :
Outdoor; Indoor
Applications :
Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an
Description

21.5-Inch Large-Format Linux Monitor for Smart City Applications and Digital Signage

The 21.5-inch high-definition monitor is a versatile solution for smart city applications, providing seamless integration with a wide array of public displays and digital signage systems. With its 1920 x 1080 resolution and vibrant 16.7 million colors, it ensures sharp and engaging visuals, making it ideal for public information kiosks, bus stop displays, or traffic control panels. The high brightness of 250 cd/m² ensures that the content remains legible even in outdoor settings, while its wide viewing angle allows for clear visibility from multiple directions. This makes the monitor perfect for dynamic content like advertising, wayfinding, and public announcements in busy urban environments.

LCD Panel ParametersScreen Size21.5 Inch
Display Area476.5 mm (Height) X 268 mm (Width)
Aspect Ratio16 : 9
LCD TypeTFT-LCD Monitor
Maximum Resolution1920 X 1080
Display Color16.7m
Brightness250cd/m²
Contrast Ratio3000 : 1
Viewing Angle (Up/Down/Left/Right)89/89/89/89 (Type)(CR≥10)
Response Time6.5ms
LCD Panel Lifespan (Hours)60,000(Hour.)
Field Frequency60Hertz
Audio parametersAudio systemStereo
Speaker size≈ 99 x 45 x 20 mm
Impedance8 Ohm
Power2 x 5 Watt
Loudness> 80 Decibel
Interface4-pin connector
Internal computer configuration
(Choose one of two)
CPUIntel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHzIntel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics CardIntegrated Graphics Card Intel® HD 4600Integrated Graphics Card Intel® HD 530
RAM4GB8GB
Storage Memory Capacity128GB256GB
OSWin10 or win11 OptionalWin10 or win11 Optional
Wi-Fi Built-inSpeed 150Mbps 802.11n wifi IntegratedSpeed 150Mbps 802.11n wifi Integrated
Media FormatVideo Formatwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio FormatMP3, WMA
Photo FormatBMP, JPEG, PNG, GIF etc.
Onboard InterfaceNetwork portRJ45 X 1, 10M/100M Adjustable Ethernet
HDMI1
USB4
PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
Maximum Power Loss≤ 45 Watt
Standby Mode Power Loss< 1 Watt
FeaturesOperating Temperature0℃ ~ 50℃
Storage TemperatureBelow 10℃ ~ +60℃
Package SizeDevice Dimensions535.9 X 332.5 X 49.95 mm.
Net Weight7 Kilogram
Package Size62 X 42 X 15Centimeter
Gross Package Weight per Unit7.5 Kilogram


In retail and advertising, this large-format monitor serves as an essential tool for digital signage and interactive displays. Its 16:9 aspect ratio and high contrast ratio of 3000:1 deliver vivid, captivating visuals, making it perfect for shopping malls, airports, and train stations, where high-traffic and high-visibility areas require eye-catching displays. With built-in Wi-Fi and Ethernet connectivity, it can easily integrate into a content management system for dynamic scheduling and remote updates, ensuring businesses can push real-time promotions, advertisements, or interactive media. The display's low power consumption also ensures energy efficiency, which is critical for installations requiring constant operation.

21.5-Inch Large-Format Linux Monitor for Smart City Applications and Digital Signage21.5-Inch Large-Format Linux Monitor for Smart City Applications and Digital Signage21.5-Inch Large-Format Linux Monitor for Smart City Applications and Digital Signage21.5-Inch Large-Format Linux Monitor for Smart City Applications and Digital Signage21.5-Inch Large-Format Linux Monitor for Smart City Applications and Digital Signage21.5-Inch Large-Format Linux Monitor for Smart City Applications and Digital Signage
For transportation hubs and public infrastructure, the 21.5-inch Linux-powered monitor offers an ideal platform for delivering critical information to commuters. It is well-suited for train stations, airports, or bus terminals where passengers require real-time updates on schedules, gate information, and safety announcements. The responsive 6.5ms refresh rate ensures that updates to information are displayed without delay, which is crucial in high-traffic environments. With built-in audio, this monitor can also support announcement systems for improved communication in public spaces, allowing for both visual and auditory alerts to be broadcast seamlessly. Its durability in varying temperatures makes it resilient for both indoor and outdoor installations, ensuring long-lasting performance in a wide range of public settings.
