The 21.5-inch large Linux monitor is designed to serve as an essential tool for smart city applications, where large-scale monitoring and data visualization are critical. In traffic management systems, this display provides real-time data such as traffic flow, vehicle counts, and incident alerts, which help traffic control centers optimize traffic signals and improve urban mobility. The high resolution and wide viewing angles ensure that city planners and engineers can view detailed analytics from various positions, offering a clear and comprehensive understanding of the data at all times. Its brightness and contrast ratio make it suitable for both indoor and outdoor applications, including interactive kiosks for public information or wayfinding in urban environments.
LCD Panel Parameters | Screen Size | 21.5 Inch | ||
Display Area | 476.5 mm (Height) X 268 mm (Width) | |||
Aspect Ratio | 16 : 9 | |||
LCD Type | TFT-LCD Monitor | |||
Maximum Resolution | 1920 X 1080 | |||
Display Color | 16.7m | |||
Brightness | 250cd/m² | |||
Contrast Ratio | 3000 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 89/89/89/89 (Type)(CR≥10) | |||
Response Time | 6.5ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 60Hertz | |||
Audio parameters | Audio system | Stereo | ||
Speaker size | ≈ 99 x 45 x 20 mm | |||
Impedance | 8 Ohm | |||
Power | 2 x 5 Watt | |||
Loudness | > 80 Decibel | |||
Interface | 4-pin connector | |||
Internal computer configuration (Choose one of two) | CPU | Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz | Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz | |
Graphics Card | Integrated Graphics Card Intel® HD 4600 | Integrated Graphics Card Intel® HD 530 | ||
RAM | 4GB | 8GB | ||
Storage Memory Capacity | 128GB | 256GB | ||
OS | Win10 or win11 Optional | Win10 or win11 Optional | ||
Wi-Fi Built-in | Speed 150Mbps 802.11n wifi Integrated | Speed 150Mbps 802.11n wifi Integrated | ||
Media Format | Video Format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. | ||
Audio Format | MP3, WMA | |||
Photo Format | BMP, JPEG, PNG, GIF etc. | |||
Onboard Interface | Network port | RJ45 X 1, 10M/100M Adjustable Ethernet | ||
HDMI | 1 | |||
USB | 4 | |||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 45 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 535.9 X 332.5 X 56.7 mm. | ||
Net Weight | 7 Kilogram | |||
Package Size | 62 X 42 X 15Centimeter | |||
Gross Package Weight per Unit | 7.5 Kilogram |
In industrial settings, the 21.5-inch monitor excels as a dashboard interface for machine monitoring systems, automation control panels, and production line displays. With its fast response time and dynamic color reproduction, it ensures smooth and accurate visualization of real-time operational data, including machine status, energy consumption, and production output. The integrated graphics and high-quality display make it perfect for use in industries such as manufacturing, logistics, and utilities, where precise monitoring and the ability to interact with control software is crucial. This monitor also features multiple connectivity options, including Ethernet and HDMI, enabling easy integration with existing systems, providing reliable performance in the most demanding environments.
The 21.5-inch monitor is also highly versatile for digital signage and interactive kiosks in public spaces or commercial establishments. In shopping malls, airports, or train stations, it can display a variety of content such as advertisements, news updates, weather forecasts, and interactive menus. Its stereo speakers and high-definition video capabilities allow it to provide both visual and auditory information, creating a more engaging experience for customers and visitors. The robust design and low power consumption make it ideal for continuous, long-term use, while its easy-to-navigate interface and integrated Wi-Fi enable seamless content updates and remote management. Whether used for wayfinding, advertising, or information dissemination, this monitor is a powerful solution for any smart city or commercial application.
