Specifications
Model Number :
ZXTLCD-RM236SA
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight case are option
Screen Size :
23.6 inch
Aspect Ratio :
16:9
Brightness :
250 cd/m²
Install Type :
Embedded, open-frame, wall-mounted, floor-standing
Suitable Environment :
Outdoor; Indoor
Applications :
Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an
Andriod OS :
10.0; 11.0
Config :
2+32GB; 4+32GB
Brand Name :
ZXTLCD
Description

23.6-Inch Android Embedded Display for Medical Diagnostics, CNC Machines, Oil and Gas Systems, and Advanced Control Panels

23.6-inch embedded LCD industrial display with Android version: A visualization tool for biotechnology research.

In the field of biotechnology research, the accurate display and efficient processing of data are crucial for the reliability of experimental results and the progress of scientific research. The 23.6-inch embedded LCD industrial display tablet running Android, with its outstanding display effect and stable system performance, has become an ideal tool for researchers to monitor data and analyze results in the laboratory, greatly enhancing the efficiency and accuracy of scientific work.

23.6-inch embedded LCD industrial display tablet running Android — Clear presentation of research data

In biotechnology research, real-time monitoring and visual presentation of experimental data are essential components of researchers' daily work. The 23.6-inch embedded LCD industrial display tablet running Android, with its high-definition display effect and wide viewing angle, can clearly present complex experimental data charts, helping researchers to quickly identify issues and make adjustments. In addition, this display features an embedded design that can seamlessly integrate with laboratory desktops or other devices, saving space while maintaining the tidiness of the lab.

23.6-Inch Android Embedded Display for Medical Diagnostics, CNC Machines, Oil and Gas Systems, and Advanced Control Panels

Research management and data analysis - 23.6-inch LCD industrial Android system

In addition to excellent display performance, the 23.6-inch LCD industrial Android system also possesses powerful data processing capabilities. Based on the openness and flexibility of the Android platform, this display can support various research software and applications, facilitating researchers in importing, analyzing, and sharing data. Moreover, this system supports remote monitoring and management, allowing researchers to view and control the status of experimental equipment in real-time over the network, even when they are not on-site in the laboratory, ensuring the smooth progress of experiments.

23.6-Inch Android Embedded Display for Medical Diagnostics, CNC Machines, Oil and Gas Systems, and Advanced Control Panels

LCD Panel Parameters Screen Size 23.6 Inch
Display Area 521.28 mm.(Height) X 293.22(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 16.7m , 72% NTSC
Brightness 250cd/
Contrast Ratio 1000 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 14ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Built-in Speaker Power 2 x 5W
Configuration PCB Android Built-in
(Choose one of two)
CPU Quad-Core RK3288, 1.8GHz Quad-Core RK3568,2.0GHz
GPU Mali-T764 Mali-G52
RAM 2GB 4GB
ROM 32GB 32GB
Android System Android 10.0 Android 11.0
Ethernet 1 x RJ45, Ethernet 1,000 Mbps 1 x RJ45, Ethernet 1,000 Mbps
Wireless Internet 2.4Gigahertz 2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth 4.2 5
Interface USB2.0 x 2 USB2.0 x 2
HDMI IN x 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 45 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Package Size Device Dimensions 569 X 341 X 51.7mm.
Net Weight 8 Kilogram
Package Size 62.7 X 40.4 X 10.5Centimeter
Gross Package Weight per Unit 9 Kilogram

23.6-Inch Android Embedded Display for Medical Diagnostics, CNC Machines, Oil and Gas Systems, and Advanced Control Panels

The 23.6-inch embedded LCD industrial display with Android, known for its excellent display effect and efficient system performance, has become an indispensable tool in the field of biotechnology research. Whether enhancing research efficiency or ensuring the accuracy of experimental data, this display has demonstrated its significant value in scientific research.
