10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals
Specifications
Model Number :
ZXTLCD-RM101SAT
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight case are option
Screen Size :
10.1 inch
Aspect Ratio :
16：9； 16：10
Brightness :
400 cd/m² max 1000 cd/m²
Install Type :
Embedded, open-frame, wall-mounted, floor-standing
Suitable Environment :
Outdoor; Indoor
Applications :
Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an
Andriod OS :
10.0; 13.0
Config :
2+32GB; 4+32GB
Brand Name :
ZXTLCD
Description

10.1-Inch Android Touch Embedded Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals

Upgrade of new energy electric vehicle charging station, 10.1-inch embedded industrial control Android touchscreen all-in-one machine brings convenient operation.

In the new energy vehicle industry, the control system of charging stations is crucial for enhancing user experience and service quality. The 10.1-inch embedded industrial control Android touchscreen all-in-one machine brings a brand new experience to new energy electric vehicle charging stations with its high-definition display effect and convenient touch operation.

10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals

10.1-inch embedded industrial control Android touchscreen all-in-one machine: High definition display, enhancing user experience

In new energy electric vehicle charging stations, the 10.1-inch embedded industrial control Android touchscreen all-in-one machine provides users with a clear perspective with its high-definition display effect. It not only accurately displays the status of the charging station and the operation manual but also enables convenient operation through Android touch technology. Moreover, its durable design allows it to operate stably for a long time in outdoor environments.

LCD Panel Parameters Screen Size 10.1 Inch
Display Area 217 mm.(Height) X 135.6(Width)mm.
Aspect Ratio 16 : 9 16 : 10
LCD Type a-Si TFT-LCD Monitor a-Si TFT-LCD Monitor
Maximum Resolution 1280 X 800 1920 X 1200
Display Color 16.7M, 50% NTSC 16.2M , 50% NTSC
Brightness 400cd/m² 1000cd/m²
Contrast Ratio 900 : 1 1000 :1
Viewing Angle (Up/Down/Left/Right) 85°/85°/85°/85° (Type)(CR≥10) 80°/80°/80°/80° (Type)(CR≥10)
Response Time 30ms 30ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
PCAP Touchscreen Panel Parameters Touch Pattern Capacitive Touchscreen Capacitive Projected
Touch Points 10 Points
Cover Glass Morse Glass Size 7 Physically reinforced to prevent explosion
Glass 3 mm. Optical mount to reduce parallax
Glass Transmission >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85%
Response Speed < 6ms
Touch Accuracy More than 90% of the touch area ±2 mm
Touch Method Inch Stylus
Output Format Coordinate Output
Click Time Unlimited
Smallest Touch Size 5 mm
Long-lasting Durability Yes, Available
Touch Interface USB
Operating Temperature and Humidity Below 10℃ ~ +50℃, ≤ 85%RH
Storage Temperature and Humidity Less than 20℃ ~ +60℃, ≤ 90%RH
Built-in Android PCB Configuration (Choose one of two) CPU Quad-Core RK3288, 1.8GHz Quad-Core RK3568,2.0GHz
GPU Mali-T764 Mali-G52
RAM 2GB 4GB
ROM 32GB 32GB
Android System Android 10.0 Android 13.0
Ethernet 1 x RJ45, 1,000 Mbps Ethernet 1,000 Mbps
Wireless Internet 2.4Gigahertz 2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth 4.2 5
Interface USB2.0 x 2 OTG USB2.0 x 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 15 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0℃ ~ 50℃
Storage Temperature Below 10℃ ~ +60℃
Package Size Device Dimensions 259.62 X 172.2 X 41.6 mm.
Net Weight 1.5 Kilogram
Package Size 31 X 23.3 X 11Centimeter
Gross Package Weight per Unit 3 Kilogram

10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals

10.1-inch industrial Android host screen: stable operation, enhancing service quality

At the same time, the 10.1-inch industrial Android host screen plays an important role in new energy electric vehicle charging stations. It not only runs various systems stably but also is compatible with various control software, providing the operator with more accurate data. Additionally, its silent design and low power consumption make it suitable for use in quiet environments.

10.1-Inch Android Embedded Touch Screen for Kiosks, Healthcare Interfaces, Smart Appliances, and Payment Terminals

The 10.1-inch embedded industrial control Android touchscreen all-in-one machine and the 10.1-inch industrial Android host screen, with their high-definition display effects and convenient touch operation, are becoming new choices for new energy electric vehicle charging stations. They not only enhance user experience but also improve service quality. In the future, with the continuous advancement of technology, they will play a greater role in new energy electric vehicle charging stations.
