Specifications
Model Number :
ZXTLCD-RM101SM
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight case are option
Screen Size :
10.1 inch
Aspect Ratio :
16:9
Brightness :
400 cd/m² max 1000 cd/m²
Install Type :
Embedded, open-frame, wall-mounted, floor-standing
Suitable Environment :
Outdoor; Indoor
Applications :
Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an
Brand Name :
ZXTLCD
Description

10.1-Inch Embedded Monitor for Kiosks, Medical Displays, Factory Dashboards, and Payment Terminals

10.1-inch custom industrial control display computer: illuminating a new perspective for subway advertising

In the subway, the artery of the city, an efficient and stable advertising display system has become key to conveying information and attracting passengers' attention. The 10.1-inch custom industrial control display computer, with its professional customization and outstanding performance, is gradually becoming the preferred device for subway advertising screens, adding a touch of vibrant technological color to urban life.

10.1-Inch Embedded Monitor for Kiosks, Medical Displays, Factory Dashboards, and Payment Terminals

10.1-inch custom industrial control display computer: born for subway advertising screens

In response to the complex and variable characteristics of the subway environment, this 10.1-inch custom industrial control display computer features a high-brightness, wide-view display screen, ensuring that promotional content is clearly presented in both bright and dim lighting conditions. Its sturdy and durable shell design effectively resists vibrations and dust during subway operations, ensuring the long-term stable operation of the equipment. At the same time, the customized production process allows each display to perfectly integrate into the subway's decorative style, enhancing the overall aesthetic.

10.1-inch Industrial Control Computer Manufacturer: Quality Assurance, Trusted Choice

As a professional manufacturer of 10.1-inch industrial control computers, we deeply understand the importance of quality for our products. From raw material procurement to production assembly, every step is strictly controlled to ensure that each display leaving the factory meets the highest industry standards. We provide comprehensive after-sales services, including installation and debugging, technical training, and long-term maintenance, allowing customers to use our products without worries. Choosing us means choosing a reliable partner to jointly create a new chapter in subway advertising.

10.1-Inch Embedded Monitor for Kiosks, Medical Displays, Factory Dashboards, and Payment Terminals

LCD Panel Parameters Screen Size 10.1 Inch
Display Area 217 mm.(Height) X 135.6(Width)mm.
Aspect Ratio 16 : 9 16 : 10
LCD Type a-Si TFT-LCD Monitor a-Si TFT-LCD Monitor
Maximum Resolution 1280 X 800 1920 X 1200
Display Color 16.7M, 50% NTSC 16.2M , 50% NTSC
Brightness 400cd/ 1000cd/
Contrast Ratio 900 : 1 1000 :1
Viewing Angle (Up/Down/Left/Right) 85°/85°/85°/85° (Type)(CR≥10) 80°/80°/80°/80° (Type)(CR≥10)
Response Time 30ms 30ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Audio Parameters
(External Speaker Option)
Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Onboard Interface HDMI Input 1
VGA Input 1
DVI Input 1
USB Type B or any desired USB Type 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 15 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Accessories Power Cord Length 1.5m
HDMI Cable Length 2m
USB-A to USB-B Cable Length 1.5m
Stereo Speaker Size with Connector 99*45*20mm
Stereo Speaker Length 1.5m
Package Size Device Dimensions 259.62 X 172.2 X 41.6 mm.
Net Weight 2 Kilogram
Package Size 31 X 23.3 X 11Centimeter
Gross Package Weight per Unit 4 Kilogram

10.1-Inch Embedded Monitor for Kiosks, Medical Displays, Factory Dashboards, and Payment Terminals

The 10.1-inch custom industrial control display computer demonstrates strong competitiveness in the subway advertising screen field with its professional customization, excellent performance, and reliable quality. It is not only a powerful assistant for subway advertising but also an important window for enhancing the city's image and conveying information. Let us work together to illuminate a new vision for subway advertising!
