13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-RM133SWT
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight case are option
Screen Size :
13.3 inch
Aspect Ratio :
16：9
Brightness :
220 cd/m²
Install Type :
Embedded, open-frame, wall-mounted, floor-standing
Suitable Environment :
Outdoor; Indoor
Applications :
Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an
Windows Versions :
10; 11
CPU :
Intel i5-4310M; Intel I5-6100T
RAM+ROM (GB) :
4+128; 8+256
Description

13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels

Upgrade of the Transportation Ticketing System, 13.3-inch Embedded Touch Industrial Tablet Brings Convenient Ticketing Experience

In the transportation industry, the convenience and stability of the ticketing system are crucial for enhancing user experience and ticketing efficiency. The 13.3-inch embedded touch industrial tablet, with its high-definition display and convenient touch operation, brings a brand new experience to the transportation ticketing system.

13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels

13.3-inch Embedded Touch Industrial Tablet: High Definition Display, Enhancing User Ticketing Experience

In the transportation ticketing system, the 13.3-inch embedded touchscreen industrial tablet provides users with a clear perspective due to its high-definition display. It not only accurately presents route information and ticket prices but also operates various control software stably, offering users a convenient operating platform. Moreover, its durable design allows it to operate stably for a long time in busy transportation environments.

13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels

13.3-inch embedded display industrial touchscreen all-in-one machine: stable operation, enhancing system reliability

At the same time, the 13.3-inch embedded display industrial touchscreen all-in-one machine also plays an important role in the transportation ticketing system. It not only runs various systems stably but also is compatible with various control software, providing the operator with more accurate data. Additionally, its silent design and low power consumption make it suitable for use in quiet environments.

LCD Panel Parameters Screen Size 13.3 Inch
Display Area 294 mm.(Height) X 165.5(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 262K, 45% NTSC
Brightness 220cd/m²
Contrast Ratio 800 : 1
Viewing Angle (Up/Down/Left/Right) 85°/85°/85°/85° (Type)(CR≥10)
Response Time 30ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
PCAP Touchscreen Panel Parameters Touch Pattern Projected Capacitive Touchscreen Monitor
Touch Points 10 Points
Cover Glass Morse Glass Size 7 Physically reinforced to prevent explosion
Glass 3 mm. Optical mount to reduce parallax
Glass Transmission >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85%
Response Speed < 6ms
Touch Accuracy More than 90% of the touch area ±2 mm
Touch Method Inch Stylus
Output Format Coordinate Output
Click Time Unlimited
Smallest Touch Size 5 mm
Long-lasting Durability Yes, Available
Touch Interface USB
Operating Temperature and Humidity Below 10℃ ~ +50℃, ≤ 85%RH
Storage Temperature and Humidity Less than 20℃ ~ +60℃, ≤ 90%RH
Audio parameters Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Internal computer configuration
(Choose one of two)		 CPU Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics Card Integrated Graphics Card Intel® HD 4600 Integrated Graphics Card Intel® HD 530
RAM 4GB 8GB
Storage Memory Capacity 128GB 256GB
OS Win10 or win11 Optional Win10 or win11 Optional
Wi-Fi Built-in Speed 150Mbps 802.11n wifi Integrated Speed 150Mbps 802.11n wifi Integrated
Media Format Video Format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio Format MP3, WMA
Photo Format BMP, JPEG, PNG, GIF etc.
Onboard Interface Network port RJ45 X 1, 10M/100M Adjustable Ethernet
HDMI 1
USB 4
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 25 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0℃ ~ 50℃
Storage Temperature Below 10℃ ~ +60℃
Package Size Device Dimensions 339 X 219 X 51.7mm.
Net Weight 3 Kilogram
Package Size 38.9 X 27.4 X 11Centimeter
Gross Package Weight per Unit 4 Kilogram

13.3-Inch Windows Touch Embedded Monitor for Retail Checkouts, Interactive Digital Signage, Smart Home Hubs, and Control Panels

The 13.3-inch embedded touchscreen industrial tablet and the 13.3-inch embedded display industrial touchscreen all-in-one machine, with their high-definition display effects and stable operation, are becoming a new choice for transportation ticketing systems. They not only enhance the user ticketing experience but also improve the reliability of the system. In the future, with the continuous advancement of technology, they will play a greater role in the transportation industry.
