18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays
18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays
18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays
18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays
18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays
18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays
18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays
18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-RM185SWT
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight case are option
Screen Size :
18.5 inch
Aspect Ratio :
16：9
Brightness :
250 cd/m²
Install Type :
Embedded, open-frame, wall-mounted, floor-standing
Suitable Environment :
Outdoor; Indoor
Applications :
Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an
Windows Versions :
10; 11
CPU :
Intel i5-4310M; Intel I5-6100T
RAM+ROM (GB) :
4+128; 8+256
Description

18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays

18.5-inch Capacitive Touch Query Industrial Control Display Host: A Powerful Assistant for Precision Instrument Control

In the field of precision instrument control, the reliability of equipment and the convenience of operation are crucial. With the continuous improvement of industrial automation, a high-performance control terminal plays a key role in enhancing work efficiency and ensuring production quality. The 18.5-inch Capacitive Touch Query Industrial Control Display Host, with its outstanding display effect and powerful functions, has become an ideal choice in this field.

18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays

18.5-inch Capacitive Touch Query Industrial Control Display Host - A Tool for Precision Control

In precision instrument control systems, the accuracy of data and the timeliness of operations directly affect the quality of the final product. The 18.5-inch capacitive touch query industrial control display host, with its high-precision touch technology and clear display effect, enables users to quickly and accurately obtain and process information. This device supports multi-touch, making complex data queries and parameter settings simple and efficient, greatly enhancing operational convenience and accuracy.

18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays

Reliable Performance and Flexible Applications — 18.5-inch Industrial Touch Display

In addition to an intuitive user interface, the 18.5-inch industrial touch display also boasts excellent durability and adaptability. Its robust design can withstand vibrations and impacts in industrial environments, ensuring long-term stable operation. In addition, this display supports a wide temperature range, maintaining good performance under various climatic conditions. Whether for controlling laboratory equipment or monitoring production lines, this display provides reliable support.

LCD Panel Parameters Screen Size 18.5 Inch
Display Area 411.3 mm.(Height) X 231.4(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 16.7m , 72% NTSC
Brightness 250cd/m²
Contrast Ratio 1200 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 14ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
PCAP Touchscreen Panel Parameters Touch Pattern Projected Capacitive Touchscreen Monitor
Touch Points 10 Points
Cover Glass Morse Glass Size 7 Physically reinforced to prevent explosion
Glass 3 mm. Optical mount to reduce parallax
Glass Transmission >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85%
Response Speed < 6ms
Touch Accuracy More than 90% of the touch area ±2 mm
Touch Method Inch Stylus
Output Format Coordinate Output
Click Time Unlimited
Smallest Touch Size 5 mm
Long-lasting Durability Yes, Available
Touch Interface USB
Operating Temperature and Humidity Below 10℃ ~ +50℃, ≤ 85%RH
Storage Temperature and Humidity Less than 20℃ ~ +60℃, ≤ 90%RH
Internal computer configuration
(Choose one of two)		 CPU Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics Card Integrated Graphics Card Intel® HD 4600 Integrated Graphics Card Intel® HD 530
RAM 4GB 8GB
Storage Memory Capacity 128GB 256GB
OS Win10 or win11 Optional Win10 or win11 Optional
Wi-Fi Built-in Speed 150Mbps 802.11n wifi Integrated Speed 150Mbps 802.11n wifi Integrated
Media Format Video Format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio Format MP3, WMA
Photo Format BMP, JPEG, PNG, GIF etc.
Onboard Interface Network port RJ45 X 1, 10M/100M Adjustable Ethernet
HDMI 1
USB 4
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 30 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0℃ ~ 50℃
Storage Temperature Below 10℃ ~ +60℃
Package Size Device Dimensions 460 X 280 X 51.7mm
Net Weight 6.5 Kilogram
Package Size 51 X 33.5 X 11Centimeter
Gross Package Weight per Unit 7 Kilogram

18.5-Inch Windows Touch Embedded Monitor for Fitness Consoles, Ticketing Systems, Vending Machines, and Wayfinding Displays

The 18.5-inch capacitive touch query industrial control all-in-one machine, with its outstanding performance and user-friendly design, has become an important component in precision instrument control systems. Whether improving production efficiency or ensuring product quality, this device demonstrates significant advantages in the field of industrial automation.
